CE Hydraulic Scrap Metal Shearing Cutting Machine HC43-2000
- 100 Set / Sets per Month
- Shanghai for CE Hydraulic Scrap Metal Shearing Cutting Machine
- T/T
- 1600 ton Heavy Duty Hydraulic Used Car Body Cutting Gantry Shear Machine OEM Accecpted
- 1600 Ton Heavy Duty Hydraulic Used Car Shell Gantry Type Shear Machine OEM Available
- 4axis 5axis Large size and thickness(0-40mm) cnc plasma cutting machine
- Automatic cnc plasma cutting machine gate cnc router 120a/200a
- Fully automatic 20mm plasma cutting machine custom size high quality
- 200mm pipe table axe for plasma metal cutting machine spare parts in weifang
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | Gaode |
Model Number: | HC43-2000 | Voltage: | 220v or in your demand | Rated Power: | 22kw |
Dimension(L*W*H): | 2400*1140*1500 | Weight: | 5.66Tons | Certification: | ISO9001:2008.CE. |
Warranty: | 6Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CE Hydraulic Scrap Metal Shearing Cutting Machine HC43-2000
Technical Specifications:
No. | TECHNICAL SPECIFICATIONS | ||||||
1 | Max Shear Force | 2000KN | |||||
2 | Max Holding Force | 250KN | |||||
3 | Shearing Frequency | 9~16 times/min | |||||
4 | Height of Working Table | 740 mm | |||||
5 | Blade Length | 800mm | |||||
6 | Max Blade Opening | 380mm | |||||
7 | Hydraulic System Pressure | 21.5MPa | |||||
8 | Control System | Hydra-electrical Valves; Push Button to Control | |||||
9 | Shearing Material Size | Round Steel | Ø75MM | ||||
Square Steel | 65*65 MM | ||||||
10 | Motor | Model | Y180M-4 | Quantity | 1 set | ||
Nominal Speed | 1460rpm | Nominal Power | 18.5 KW | ||||
11 | Hydraulic Pump | Model | 80YCY14-1B | Quantity | 1set | ||
Nominal Outflow | 80ml/r | Nominal Pressure | 31.5MPa | ||||
GAODE Hydraulic Machinery has been a trusted name in the waste recycling equipment industry for over a decade as a dedicated Chinese manufacturer of scrap metal recycling equipment, our flagship products includethe shear baler, scrap baler, scrap shear, and recycling crane.
In addition to scrap metal processing equipment, we also supply horizontal baler and vertical baler for compacting plastic, paper, cardboard, straw, textile and more types of wastes.Our company was first inaugurated in 2003.
Our GAODE brand has received critical acclaim both domestically and overseas. As a trusted waste recycling equipment manufacturer, we have successfully passed the certification of both the TUV and the ISO9001 Quality Management System. We are currently in the process of obtaining the approval of European standards such as CE and UL.
Finished Products
The Exhibition
Our Certificate
Our Factory
6months guarantee for whole machine
24hours technical support by email
Calling or door to door service
User manual and detailed video
Jiangsu Gaode Hydraulic Machinery Co,Ltd.
Apple Zhang
Trademanager:cn200094822
TEL: 86-510-86996082 18921250082
FAX: 86-510-86993993
ADD: NO.691, Chengshan Road, Jiangyin City, Jiangsu Province, China.
Q1:Can I add my logo on the machines?
A: Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q2:How can i get the after-service?
A: We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems,we also send the spare parts,but you should pay.
Q3:Do you have inspection procedures for machines?
A:100% self-inspection before packing
Q4:Can I have a visit to your factory before the order?
A:Sure,welcome to visit our factory.
Here is our factory address:No.691, Chengshan Road, Jiangyin City, Jiangsu Province, China.
Q5: Can we order one set machine?
A:Yes, you can.
