Safe effective discarded stainless steel shear
Technical Specifications:
| TECHNICAL SPECIFICATIONS | ||||||
1 | Max Shear Force | 2000KN | |||||
2 | Max Holding Force | 250KN | |||||
3 | Shearing Frequency | 9~16 times/min | |||||
4 | Height of Working Table | 740 mm | |||||
5 | Blade Length | 600mm | |||||
6 | Max Blade Opening | 280mm | |||||
7 | Hydraulic System Pressure | 21.5MPa | |||||
8 | Control System | Hydra-electrical Valves; Push Button to Control | |||||
9 | Shearing Material Size | Round Steel | Ø35MM | ||||
Square Steel | 30*30 MM | ||||||
10 | Motor | Model | Y180M-4 | Quantity | 1 set | ||
Nominal Speed | 1460rpm | Nominal Power | 18.5 KW | ||||
11 | Hydraulic Pump | Model | 80YCY14-1B | Quantity | 1set | ||
Nominal Outflow | 80ml/r | Nominal Pressure | 31.5MPa | ||||
Product Flow:
Packaging Detail: in nude
Delivery Detail: 20-25 working days
Exhibition:
Factory:
Jiangyin Gaode Hydraulic Machinery Co,Ltd. We are the professional manufacture of hydraulic machinery and scrap proccessing equipment . As we all known, there are abundant technical force, advanced test equipment and technology and completed testing means.
Jolie
Sales representative
Jiangsu Gaode Hydraulic Machinery Co.,Ltd
China factory
ADD: No. 691 Chengshan Road, Jiangyin City, Jiangsu Province.
Tel: +86 510 86996082/ 15261635390 (7*24 hours online service)
Fax: +86 510 86993993
