Hydraulic Hand Pallet Stacker of China

Product Introduction

  hydraulic hand pallet stacker SYC series

• The forks of SYC series manual stacker are forged forks.The lifting height of single mast manual stacker is 1.6m
• and the lifting height of dual mast stacker is 2.5m and 3m.
• 1.6m manual stacker is equipped with single mast.

Main Parameter

Model                           unit    SYC0516
Rated load                    kg      500
Load center distance    mm     400
Fork minimum height    mm     85
Fork maximum height   mm   1600
Fork length                   mm    800
Outer width of forks      mm    750
Front fork leg center width mm 470
Minimum turning radius mm 1110
Wheel base between front wheel mm 996
and rear wheel
Distance between brackets of mm 213
front wheel
Machine length mm 1280
Machine width mm 800
Machine height mm 1980
Machine weight kg 155
