Hydraulic Stone Splitter Introduction
Cheapest Price Hydraulic Stone Splitter For Sales
Hydraulic Stone Splitter is our newly developed Product which is a powerful and extremely cost effective alternative to other conventional demolition tools. It can develop a very huge splitting force (Maximum 1000 T) when it put into the pre- drill holes of rock or concrete and crack it into pieces within several seconds
It is widely used in mineral mining (cave mining), civil engineering construction and demolition. It is also an indispensable tool in construction, river dredging, salvation etc.
Hydraulic Stone Splitter Main Parameter
Model | Piston Diameter | Hole Diameter | Hole Depth(mm) | The length of the wedge | crack width | Split time | Theoretical splitting force | The actual split force |
(Type) | (MM) | (MM) | (MM) | (MM) | (mm) | (S) | (T) | (T) |
ZM( 32-38)A | 80 | Φ32~38 | ≥300 | 150 | 10~35 | 5~12 | 500 | 280 |
ZM( 38-40)A | 80 | Φ38~42 | ≥300 | 150 | 10~40 | 5~12 | 500 | 280 |
ZM( 38-40)B | 80 | Φ38~42 | ≥400 | 200/250 | 10~40 | 5~12 | 650/600 | 350/300 |
ZM( 40-42) | 90 | Φ42~46 | ≥600 | 300 | 10~40 | 5~12 | 680 | 420 |
ZM( 42-46) | 90 | Φ42~46 | ≥600 | 380 | 10~40 | 5~12 | 650 | 500 |
ZM( 44-46)A | 100 | Φ44~46 | ≥600 | 300/380 | 10~40 | 5~12 | 780 | 550 |
ZM( 44-46)B | 105 | Φ44~46 | ≥600 | 300/380 | 10~40 | 5~12 | 880 | 600 |
ZM( 46-48) | 110 | Φ46~48 | ≥600 | 300/380 | 10~40 | 5~12 | 1080 | 700 |
Poewr pump pack | Dimension(mm) | weight(kg) | Tank capability(L) | Engine power | pressure(MPa) | Flux(L/m) | Splitting(pc) |
Diesel engine | 1150*1180*940 | 120 | 40 | 6Hp | 55-60 | 2-13 | 1-10 |
Cheapest Price Hydraulic Stone Splitter For Sales Figure Photos
