Applications of China Coal Group Tractor Mounted Water Well Drilling Rig Tripod Drilling Rig
China Coal Group Tractor Mounted Water Well Drilling Rig Tripod Drilling Rig is a new, efficient, semi-mechanized and advanced drilling equipment. It has been widely used in coal mine, ore mine, stone quarry, and energy industry,it take the design of single piston, plate valve and the combination of exhaust joint and reducer joint, method changed from directly reducing to conically reducing. it has high efficiency. And China Coal Group Tractor Mounted Water Well Drilling Rig Tripod Drilling Rig could drill hard rock with rock hardness f = 6-20.
Features of China Coal Group Tractor Mounted Water Well Drilling Rig Tripod Drilling Rig
1. The design of trinity can effectively reduce production cost
2, When Best Price Portable Down The Hole Hammer Drilling Rig Machine is blocked and needs to be lifted, the design of taper adjusting will lessen the lifting resistance and lower the probability of trouble.
3.The special new craft of temperature control with micro-computer is used to protect main parts from dust pollution produced by drilling operation. Water could be added into compressed air to wet the rocks when drilling, and to keep operator healthy.
4, Best Price Portable Down The Hole Hammer Drilling Rig Machine has the advantages of light weight, High efficiency, good performance, drill hard rock with rock hardness f = 6-20. Easy to operate
5. Economical. Reasonable and competitive price.
Parameter of BeChina Coal Group Tractor Mounted Water Well Drilling Rig Tripod Drilling Rig
Main Machine Technical Parameter | |
Model |
zm100 |
Borehole diameter |
80-110mm |
Rock type |
Rock, hard rock, f=6-20 |
Bore depth |
20-80m |
Matched hammer |
90-150 |
Drill rotation speed |
90 r/min |
Length once |
1.5m |
Air pressure |
0.5-0.7Mpa |
Air consumption |
7-12 m³/min |
Drilling hammer |
Q70 |
Drilling Rod | |
Outer diameter |
60mm |
Rod length |
1026mm |
Weight of rod |
7.2kg |
Electric Motor | |
Power |
5.5KW |
Voltage |
380V |
Overall Dimension | |
Length |
2380mm |
Height |
470mm |
Weight |
195KG |
Images of China Coal Group Tractor Mounted Water Well Drilling Rig Tripod Drilling Rig
