High efficiency drilling rig machine in mine drilling rig
- 500 Set / Sets per Month
- Qingdao or according to your requests
- T/T Credit Card
- China Xy-200 Water Well Drill Rig Machine for Soil and Rock Drilling
- 100 Meters Xy-1A Water Well Drilling Rig Machine Equipment
- HY-50H Small Domestic Hydraulic Water Well Drilling Rig of China
- 50m Depth Core Drilling Rig Portable Diamond in Mountain
- TSP core bit, BQ NQ HQ PQ core drill bits, HWL, wireline core barrels, diamond coring bits, hard formation, deep hole rock core recovery
- 1.5M 3M inner tube assembly, wireline core barrels, head assembly, impregnated diamond drilling, hard formation coring, deep hole rock core recovery
Product Details
Condition: | New | Type: | Rotary Drilling Rig | Power Type: | Electric |
Place of Origin: | Shandong, China | Brand Name: | China Coal | Model Number: | ZM-100 |
Usage: | Coal | Voltage: | 2 | Power(W): | 4 kw |
Dimension(L*W*H): | 1*1*1 | Weight: | 175kg | Certification: | ce/ma |
Warranty: | 1 year | After-sales Service Provided: | Overseas third-party support available |
Product Description
Applications of Downhole Drilling Rig Machine Water Well Drilling Rig Mobile Drilling Machine
The electric Downhole Drilling Rig Machine Water Well Drilling Rig Mobile Drilling Machine is a new, efficient, semi-mechanized and advanced drilling equipment. It has been widely used in coal mine, ore mine, stone quarry, and energy industry,it take the design of single piston, plate valve and the combination of exhaust joint and reducer joint, method changed from directly reducing to conically reducing. it has high efficiency. And Downhole Drilling Rig Machine Water Well Drilling Rig Mobile Drilling Machinecould drill hard rock with rock hardness f = 6-20.
Features of Downhole Drilling Rig Machine Water Well Drilling Rig Mobile Drilling Machine
1. The design of trinity can effectively reduce production cost
2, When Downhole Drilling Rig Machine Water Well Drilling Rig Mobile Drilling Machine is blocked and needs to be lifted, the design of taper adjusting will lessen the lifting resistance and lower the probability of trouble.
3.The special new craft of temperature control with micro-computer is used to protect main parts from dust pollution produced by drilling operation. Water could be added into compressed air to wet the rocks when drilling, and to keep operator healthy.
4, Downhole Drilling Rig Machine Water Well Drilling Rig Mobile Drilling Machine has the advantages of light weight, High efficiency, good performance, drill hard rock with rock hardness f = 6-20. Easy to operate
5. Economical. Reasonable and competitive price.
Parameter of Downhole Drilling Rig Machine Water Well Drilling Rig Mobile Drilling Machine
Main Machine Technical Parameter | |
Model | zm100 |
Borehole diameter | 80-110mm |
Rock type | Rock, hard rock, f=6-20 |
Bore depth | 20-80m |
Matched hammer | 90-150 |
Drill rotation speed | 90 r/min |
Length once | 1.5m |
Air pressure | 0.5-0.7Mpa |
Air consumption | 7-12 m³/min |
Drilling hammer | Q70 |
Drilling Rod | |
Outer diameter | 60mm |
Rod length | 1026mm |
Weight of rod | 7.2kg |
Electric Motor | |
Power | 5.5KW |
Voltage | 380V |
Overall Dimension | |
Length | 2380mm |
Height | 470mm |
Weight | 195KG |
Images of Downhole Drilling Rig Machine Water Well Drilling Rig Mobile Drilling Machine
