Product Details
Brand Name: | CHINACOAL | Model Number: | HC18 | Condition: | New |
Moving Type: | Crawler Excavator | Operating Weight: | 6000kg | Bucket capacity: | 0.05m3 |
Maximum Digging Height: | 3150mm | Maximum Digging Depth: | 2100mm | Machine Weight: | 1710kg |
Max Digging Radius: | 3705mm | Rated Speed: | 5.5km/h | Certification: | CE ISO |
After-sales Service Provided: | No overseas service provided |
Product Description
Introduction of mini digger for garden use
1.Equipped with imported from KUBOTA engine ,in line with state Ⅲ emission.
2.All imported hydraulic system,the load sensitive technology ,has the good operation performance and efficiency .
3.Using one rotary structure ,car body tail in any stage are not beyond the crawler ,movable arm deflection function ,ensures the narrow strip of flexible operations.
4.The chassis is elastic structure ,it has the good through performance .
5.Standard proprietary suspension type ,can be selected according to the requirements of using steel crawler ,completely interchangeable .
6.The driving tent is an assembled structure ,which can be easily disassemble and optional .
7.After the hood and side cover are based on open structure and easy maintenance .
8.The standard accessory device pipeline ,the user can input the installation of broken hammer ,etc.
9.Working device bushing are all made of high strength graphite copper sleeve ,effectively reduce the noise ,prolong the butter filling time .
10.Choose luxurious seats,can adjust themselves to meet the need of the driver ,improve the comfortableness.
Main Parameter of mini digger for garden use
Specification | ||
Standard Bucket Capacity (SAE) | M 3 | 0.05 |
MaX Digging force(ISO) | KN | 15.2 |
Unit swing speed | rpm | 9.5 |
Travel speed | Km/h | 2.1/4.3 |
Ground pressure | kpa | 29.6 |
Fuel reservoir | L | 22 |
Engine | ||
Model | KubotaD1105 | |
Rated power | KW | 14.2 |
Type | Vertical3-Cycle liquid Cooled Diesel | |
Hydraulic System | ||
Flow | L/min | 39.6 |
Operating Pressure | Mpa | 20.6 |
Type | Full hydraulic pilot operated ,Load Sensing System | |
Dimensions | ||
Transport length | mm | 3752 |
Width | mm | 980/1300 |
Height | mm | 2356 |
Min ground clearance | mm | 172 |
Track width | mm | 230 |
Gauge | mm | 750/1070 |
Working range | ||
Max digging height | mm | 3556 |
Max dumping height | mm | 2452 |
Max digging depth | mm | 2247 |
Max digging radius | mm | 4045 |
Max digging radius at ground | mm | 3784 |
Min tail turning radius | mm | 650 |
Min turning radius | mm | 780 |
Boom Swing Angle | mm | 45(LH)/55(RH) |
Figure Images of mini digger for garden use
