Specifications
PP PE film pelletizer1.output: 100-800kg/h pe pp recycling granulation line
2. CE pe pp film pelletizing machine
Feature and Function of pe pp PP PE film pelletizer :
Water ring type pelletizing line,recycling PP PE film bags,make them into pellets.
Process flow of the pe pp film pelletizing machine:
Conveyor→ PE film compactor→ Extruding system→ Die-head and High speed Net exchanging system→ water ring pelletizing machine → water tank → dewatering machine→ vibrating sieve→ Air Blower → Storage hopper
Detailed description of pe pp film pelletizing machine
1. Conveyor:convey PP PE film or flakes into compactor.
2. PE film compactor:crushing and compress film,and feed compressed film into extruder forcedly,to make the production capacity high and stable.
3.Extruding system:plasticizing material and exhausting gas.
4.High speed Net exchanging system and Die-head:filter material impurity,to make production more stable.
5.water ring pelletizing machine:cutting pellets in water.
6.Water tank:cooling pellets.
7.Dewater machine:make pellets dry.
8.Vibration sieve:remove bad pellet and keep good pellet.
9.Air Blower:convey good pellets into silo.
10:Storage silo:keep pellet.
Thecnical parameters of pe pp film pelletizing machine
Model |
L/D |
Output |
Speed of Screw Rotation |
Power |
Center Height |
SJ-50/33 |
33:1 |
20-80 kg/h |
12.5-130 r/min |
37kw |
1000 mm |
SJ-65/33 |
33:1 |
80-150 kg/h |
33-130 r/min 20-120r/min |
45kw 55kw |
1000 mm |
SJ-75/33 |
33:1 |
120-280 kg/h |
20-120 r/min |
75kw 90kw |
1000 mm |
SJ-90/33 |
33:1 |
150-450 kg/h |
33.3-110 r/min |
110kw 160kw |
1000 mm |
SJ-120/33 |
33:1 |
300-600 kg/h |
20-100 r/min |
260kw |
1200 mm |
SJ-150/33 |
33:1 |
450-700 kg/h |
7-80 r/min |
315kw |
1200 mm |
key words
PE PP pelletizing pelletizer granulating granulator machine recycling production line
plastic pelletizing /granulating machine
pelletizing production line
