Plastic Agglomerator/densifier/fiber Agglomerator

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Recycling Granulator
Capacity	100-800kg/h	Place of Origin	Jiangsu, China
Brand Name	sevenstars	Model Number	BDX
Material	Other	Screw Design	Other
Voltage	380V 50HZ or customized	Power	37-132KW
Dimension(LWH)	per different capacity	Weight	1200-3500kg
Certification	CE ISO	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

agglomerator
1.Strong design of double-bearing
2.High performance blades
3.Temperature control and water automatically

Agglomerator
1.Strong design of double-bearing
2.High performance blades
3.Temperature control and water automatically

The Agglomerator ( Densifier ) is used for densify LDPE,LLDPE,HDPE,PP, PET, BOPP film and bags.

Main parameters of Agglomerator GHX

GHX	1000	800	500	300	200	100
Tank volume (Liter)	1000	800	500	300	200	100
Working volume (Liter)	750	600	375	200	150	75
Capacity( Kg/h)	600~800	400~650	350~500	200~350	150-250	100-150
Motor power (Kw)	132	110	90	75	55	37
Rotating blades speed (r/min)	700	750	750	900	800	800
Rotating blades quantity (pcs)	4	4	4	2	2	2
Stationary blades quantity(pcs)	8	8	8	8	6	6
Discharging model	Pneumatic	Pneumatic	Pneumatic	Pneumatic	Pneumatic	Pneumatic
Water inlet	1”	1”	1”	1”	1”	1”
Machine dimension L×W×H (mm)	2680×1815×2400	2170×1510×2140	2100×1510×2145	2100×1495×1945	1900×1160×1800	1900×650×1310
Machine weight ( Kg)	3500	2800	2500	2000	1800	1200

agglomerator/densifer plastic agglomerator agglomerator densifier machine
