Help CenterPlastic Glazed Roof Tile Production Line
Related Products
-
High Quality PVC Tile Producing LineUS$ 5,000 - 1,500,000MOQ: 1 Set -
PVC Waving Roofing Tile Producing LineUS$ 5,000 - 1,500,000MOQ: 1 Set
-
PVC Plastic Waving Tile Producing MachineUS$ 5,000 - 1,500,000MOQ: 1 Set
-
PVC Waving Roofing Tile Producing Line/extrusion LineUS$ 5,000 - 1,500,000MOQ: 1 Set
-
PVC Composite Corrugated Tile Extrusion Line/MachineUS$ 140,000 - 150,000MOQ: 1 Set
Specifications
plastic glazed roof tile production line1.High capacity
2.Efficient extruders
3.Smooth products
4.Long life
Features of plastic glazed roof tile production line :
1. Adopt PLC control and simple operation .
2. Adopt Electric-magnetic heater which can save 40% -60% electric power for customer .
3. All Electric Part (breaker/motor/relay /Inverter and so on ) is Siemens/Schneider/Omron
4. Adopt Gravity Feeding System
5. Material of screw and barrel: 38CrMoAlA, nitrogen quenched which the thickness layer 0.4-0.7mm; Hardness of screw barrel: >940 HV;
6. Unique grooved structure feed bush with force cooling system that is specially designed by Friend co. which can increase output at 15-20%.
7. Variable screw-pitch and double-separate structure screw is specially designed for PE. Comprehensive plasticizing element, ensure the plasticizing effects of materials.
8. The water cooling tank has two vacuum chambers which can improve cooling effect .
9. This line includes automatic forced feeding system/conical extruder/die head and mold/calibration unit/chilling unit/hauling unit/cutting unit/stacker .
Technical Parameters of PVC Wave Roof Tile Machine
Product |
Product thickness |
Extruder |
Max. output |
Total Length |
880mm |
2-4mm |
SJSZ-80/156 |
390kg/h |
customizing |
1040mm |
2-4mm |
SJSZ-80/156 |
420kg/h |
customizing |
