Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption

Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption thumbnail-1
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption thumbnail-2
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption thumbnail-3
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption thumbnail-4
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption thumbnail-5
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption thumbnail-6
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption photo-1
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption photo-2
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption photo-3
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption photo-4
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption photo-5
Plastic Film Scraps Granules Machine PP/PE/PET,fiber Plastic Film Agglomerator Machine Low Power Consumption photo-6
US$ 2,500 - 8,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Granulating Production Line
Capacity:
100-800kg/h
Contact Supplier Request Quote Chat Now
Zhangjiagang Horse Rider Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Granulating Production Line
Capacity 100-800kg/h
Place of Origin Jiangsu, China
Brand Name Zhangjiagang Horserider Machinery
Model Number GHX series for film agglomerator
Material Other, PP PE PET fiber plastic agglomerator machine
Screw Design Other, customerized for film agglomerator
Voltage 380v or customerized for film agglomerator
Power 37-132 Kw
Dimension(L*W*H) according to the capacity
Weight 4000kg
Certification CE, TUV, ISO9001
Warranty 15 Months
After-sales Service Provided Engineers available to service machinery overseas



plastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumption

Application



Granulator agglomerator machine were widely used in aggregating plastic ,such as PE film , PP, BOPP, PET film, fibers and so on. The processed material can be feeded to extruder machine more easier and hence increase the capacity of granulator machine.Agglomerator can directly make waste plastic films and PET chips and PET/PP fiber and some other textile products into granules. It is suitable to agglomerate the waste products or films made of soft PVC, PET, HDPE, LDPE, PP and other thermo plastics.



Advantageous Features

1.Strong design of double-bearing for holding the main shaft
2.High performance blades
3.Temperature control
4.Water flushing automatically
5. low consumption, High quality PE PET Fiber agglomerator machine
6.Processing capacity from 50kg/h to 500kg/h





The particles can be used for extrusion or injection mould machine directly. Also it can be further pelletized for some advanced requirements.



This machine is qualified with certificate ISO9001:2000 and CE certificate.



Model

Volume(L)

Effective

Volume(L)

Motor

Power(KW)

Main shaft

Speed(rpm)

Capacity

(kg/hr)

Heating

Method

Discharge

Method

GHX-100

100

75

37

800

80-100

By self

friction

Manually or

Pneumatic

GHX-200

200

150

55

800

150-200

GHX-300

300

225

65

800

250-300

GHX-450

400

350

75

800

350-400

GHX-500

500

450

90

750

450-500

GHX-600

600

550

110

750

550-600

GHX-800

800

650

110

750

750-800

Material of barrel: Stainless steel

Blade material: 9CrSi





plastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumptionplastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumption



plastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumption



plastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumption



plastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumption



plastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumption



plastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumptionplastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumptionplastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumptionplastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumptionplastic film scraps granules machine PP/PE/PET,fiber plastic film agglomerator machine low power consumption





If you have any further problems, Plz feel free to contact me:
 Mobile:      +86-18749556798

Whatsapp : +86-18749556798
