Crawler Type geothermal Small Water Well Drill Rig for Sale
water well drilling rig
Used for general investigation, geophysical exploration, high-way and building construction, and blast-hole drilling etc.With hydro-automatic feeding device, and high drilling efficiency.
Designed with hydro-chucking unit instead of slips to ensure drilling from stop when changing pipes.Close levers, convenient to operate, safe and reliable operations.
Compact in structure. All the drill, water pump and diesel engine installed on one base frame result in space-saving.Light in weight, easy disassembling for transportation and applicable to working conditions in plain and mountain areas.
Unity machine parameter | ||
Drilling depth | 30--200m | |
End hole caliber | 500-75mm | |
Drill rod caliber | 50mm | |
Drilling angle | 90°~75° | |
Drill weight (No include power) | 910kg | |
Unity machine dimensions | 2.5×1×1.3 2.5×0.9×1.3m | |
Spindle | ||
spindle speed | 64,128,287,557r/min | |
Spindle stroke | 450mm | |
Hoist | ||
Max.single line hoisting capacity | 2500KG | |
Single line lifting speed | 17,35,75,151r/min | |
Tightrope caliber | 12.5mm | |
Tightrope cubic measure | 35m | |
Hug floodgate caliber | 254mm | |
Hug folldgate belt width | 70mm | |
Distance between drill and hole | 400mm | |
Mud pump - Specifications | ||
Type | Horizontal single urn twin-action | |
Displacement | 170L/min | |
Diesle engine | S1115 model 22HP | |
Electric motor | Y160M—4 15kw 1440r/min | |
Maximum pressure | 1.5Mpa | |
Work pressure | 0.7Mpa | |
Water inlet caliber | 40mm | |
Water to exit caliber | 30mm | |
Triangle conveyer belt | B1728mm | |
Suit scope | ||
Water well , exploration | ||
Sample picture
water well drilling rig
