Home > Products > New Products > China Three Function in One Multi-function Busbar Processing Machine
China Three Function in One Multi-function Busbar Processing Machine
- Qingdao port
- Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | HW | Model Number | HW888-2 | |
| Machine Type | Beading Machine | Raw Material | Steel Bar | |
| Material / Metal Processed | PVC | Power | Cnc | |
| Automation | Automatic | Extra Services | Cut To Length | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
China Three function in one multi-function busbar processing machine
Application :
This processor is suitable for making large electric cabinet ,power distribution cabinets ,switch cabinets and
power transmission and distribution construction engineering construction site use.
Feature :
This machine is with reference to foreign advanced products ,combined with domestic practical situation , to provide the efficiency and guarantee of safety requirement and the design of form a complete set of equipment .
Most suitable for making large electric cabinet and transmission and distribution construction project fields use .
High flexibility , small volume , big power , high production capacity and high work efficiency .Low noise,
harmless processing . Finishing product is beautiful and won’t cause pollution to the environment.
Function | Item | MODEL | |||
HW-303 | HW-503 | HW-303S | HW-503S | ||
Punching | Max. Punching Force (KN) | 300 | 500 | 300 | 500 |
Punching Diameter Range (MM) | Ø4.3-Ø25 | Ø4.3-Ø34 | Ø4.3-Ø25 | Ø4.3-Ø34 | |
Max. Thickness (MM) | 12 | 16 | 12 | 16 | |
Max. Width (MM) | 150 | 200 | 150 | 200 | |
Shearing/Cutting | Max. Shearing Thickness (MM) | 12 | 16 | 12 | 16 |
Max. Shearing Width (MM) | 150 | 200 | 150 | 200 | |
Honrizental Bending | Max. Bending Force (KN) | 300 | 500 | 300 | 500 |
Max. Thickness (MM) | 150 | 200 | 150 | 200 | |
Max. Width (MM) | 12 | 16 | 12 | 16 | |
Vertical Bending | Max. Width (MM) | 100 | 120 | 100 | 120 |
Max. Angle (Degree) | 90° | 90° | 90° | 90° | |
Out Dimension | MM | 1670*1200*1200 | 1800*1500*1300 | 1770*1400*1300 | 1980*1550*1460 |
Power | KW | 3*4kw | 3*5.5kw | 3*4kw | 3*5.5kw |
Weight | KG | 1200kg | 1750kg | 1360kg | 2200kg |
CNC Precision | Bending Precision | ±1° | ±1° | ±1° | ±1° |
Repeat Bending Precision | ±0.3° | ±0.3° | ±0.3° | ±0.3° | |
reliable chinese supplier for multi function Busbar Processing Machine
cnc copper busbar machine
Contact Us
- Jining Hengwang Mining Machinery Co., Ltd.
- Contact nameAmy Jiang Chat Now
- Phone86-537-2886068
- Address537-, Jining, Shandong
