New Small Portable Shallow Well Drilling Used Cheap Water Well Drilling Rig Price for Sale

FOB Price

US$ 5,000 - 5,720 / Set

1 Set(Min. Order)

Port Qingdao Shanghai Tianjin

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary Drilling Rig
Power Type	Diesel	Place of Origin	Shandong, China
Brand Name	HengWang water well drilling rig	Model Number	HW-130Y/YY
Usage	Water Well	Voltage	220V/380V,can be customized
Power(W)	diesel prower	Dimension(LWH)	250010001300 mm
Weight	975KG	Certification	ISO CE
Warranty	1 years	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Hydraulic small water well drill rig machine for deep water well at cheapest price

Product Description

water well drilling rig

Used for general investigation, geophysical exploration, high-way and building construction, and blast-hole drilling etc.With hydro-automatic feeding device, and high drilling efficiency.

Designed with hydro-chucking unit instead of slips to ensure drilling from stop when changing pipes.Close levers, convenient to operate, safe and reliable operations.

Compact in structure. All the drill, water pump and diesel engine installed on one base frame result in space-saving.Light in weight, easy disassembling for transportation and applicable to working conditions in plain and mountain areas.

Specifications
Unity machine parameter
Drilling depth	10-130m
Maximum open hole caliber	260mm
End hole caliber	75mm
Drill rod caliber	50mm
Drilling angle	90~75
Drill weight (No include power)	510 560kg
Unity machine dimensions	2.5×1×1.3 2.5×0.9×1.3m
Spindle
spindle speed	142,285,570r/min
Spindle stroke	450mm
Hoist
Max.single line hoisting capacity	960kg
Single line lifting speed	0.41,0.82,1.64m/s
Tightrope caliber	27m
Mud pump of HZ-130YY model drilling rig
Type	Horizontal single urn twin-action
Displacement	95/77L/min
Diesle engine	s1115 or 22HP
Electric motor	Y160M—4 11kw 1440r/min
Maximum pressure	1.2Mpa
Work pressure	0.7Mpa
Water inlet caliber	30mm
Water to exit caliber	25mm
Triangle conveyer belt	B1575mm

Sample picture
