Specifications
JL-16 Type Block Machine2.mold box with limited switch
3.Upper, front and back vibrations
5.withISO9001,2008&CE
JL-16 Type Block Shaping Machine
About JL-16 Type Block Shaping Machine
1.The machine is all made through welding with strong square steel and extremely solid and vibration-resistant and its working stability is very excellent.
2.Mold box adopts double-column sliding;with compact coordination and stable synchronous lifting.Shaping ratio of block improves substantially.
3.Aggregate head can slide and move, and cloth of mold box is convenient,which greatly improves work efficiency.
4.Lifting position of mold box is installed with limited switch,which can prevent aggregate head from damaging machine.
Characteristics as follows:
Upper, front and back vibrations are carried out at the same time,which makes the four walls of mold box receive even force,achieves optimum shaping effect and ensures high degree of compactness of block brick ,orderly beatiful edge angle and immediate stacking after shaping.
Main Tecnnical Parameter:
| Vibration reduction force | 70KN |
| Vibration frequency | 5000t/min |
| Amplitute | 15mm |
| Noise | 92db |
| Time of vibration | 2-3s/t |
| Shaping cycle | 15s/t |
| Installed capacity | 18.5kw |
| Weight | 4300 kg |
Certification:
