China Artificial sand making machine with CE
- nearest port
- T/T Credit Card
You May Like
-
Third generation high efficiency fine crusher with ISO and CE
-
Saving-energy fifth-generation sand making machine supplier
-
Saving-energy fifth-generation sand maker supplier in China
-
China high quality Artificial sand maker with CE
-
third generation high efficiency sand maker machine with ISO
-
Energy-efficient iron ore sand making machine with ISO
Product Details
| Production Capacity | depend on model | |||
| Place of Origin | Henan, China | Brand Name | Henan Kefan | |
| Model Number | KF | Voltage | 380 v | |
| Power(W) | 37-45 kw | Dimension(L*W*H) | 2800*1550*2030 mm | |
| Weight | 5.6 t | Certification | BV/CE/ISO | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Artificial sand making machine1)high yield, large crushing ratio;
2)easy installation and maintenance;
3)easy to operate
Artificial sand making machine produced by our company make stone fal from the upper of the crusher into the high-speed rotation of the impeller directly,under the function of high speed centrifugal force, toghter with other parts, umbrella-type manner shunt around the impeller speed target stone impact generated and high density pulverized stone hit each other, then they will form between the turntable and the chassis number of the vortex caused by movement against each other, friction, grinding, pulverizing until the desired particle size.
Artificial sand making machine features:
1. this product is the latest type sand making machine, is the replaced products of cone crusher, roller crusher, ball mill, sand making models;
2. small energy consumption, high yield, large crushing ratio;
3. devices are small, easy to operate, easy installation and maintenance.
4. in the production process, can form a protective stone bottom, the body no wear and durability.
5. working noise is below 75 decibels (db level), less dust pollution.
Artificial sand making machine technical parameters:
Artificial sand making machine | Rotor width(mm) | Rotor width (mm) | Rotor width (mm) | Rotor width (mm) | Rotor width (mm) |
Model specification | 800×400 | 800×600 | 800×800 | 1010×1010 | 1200×1000 |
Feeding port size(mm) | 400×185 | 500×250 | 550×330 | 1000×350 | 1200×400 |
Feeding size(mm) | <120 | <180 | <180 | <180 | <180 |
Discharging size(mm) | <5 | <5 | <5 | <5 | <5 |
stitch width adjustment | 5-20 | 5-20 | 5-20 | 5-20 | 5-20 |
Cement clinker (T/H) | 20-30 | 35-40 | 35-45 | 45-55 | 80-110 |
Limestone(T/H) | 35-45 | 45-55 | 55-65 | 65-75 | 50-100 |
Matched power(KW) | 37-45 | 45-55 | 45-55 | 55-75 | 100-110 |
