Specifications
1.Advanced technology,2.Low power consumption,
3.Guanranteed quality with CE/ISO,
4.High productivity,best performance
Introduction of vibrating screen
The vibrating equipment is an efficient new equipment. The multi-layer vibration equipment for stone quarries and sand filters can also be used as classification processing, building materials, electricity, coal, the role of chemical industry products with the sound vibration of a small, reliable structure, high efficiency, durable, safe and convenient features.
Working Principle of vibrating screen
Vibrating Screen consists of screen box, supporting device, vibration exciter, transmission part, etc. The barrel-type vibration exciter is installed in the middle of the machine. During normal operation, the vibration of exciter will drive the screen mesh fixed on the screen box vibrate, and then materials will be screened. The big and small materials fall from the upper side and lower side of the screen to get them separated.
Main Technical Parameters of vibrating screen
Model |
Screen Size |
Screen Decks |
Screen Hole Size |
Max. Feeding Size |
Capacity |
Motor Power |
Weight |
Overall |
2YZS1237 |
3700×1200 |
2 |
3-50 |
200 |
10-80 |
11 |
2.40 |
4773×2050×2247 |
3YZS1237 |
3700×1200 |
3 |
3-50 |
200 |
10-80 |
11 |
3.05 |
4773×2050×2700 |
2YZS1548 |
4800×1500 |
2 |
3-100 |
400 |
30-200 |
15 |
5.35 |
5900×2270×1620 |
3YZS1548 |
4800×1500 |
3 |
3-100 |
400 |
30-200 |
15 |
6.07 |
5900×2270×1670 |
2YZS1848 |
4800×1800 |
2 |
3-100 |
400 |
50-280 |
18.5 |
6.15 |
5900×2560×1620 |
3YZS1848 |
4800×1800 |
3 |
3-100 |
400 |
50-280 |
18.5 |
6.93 |
5900×2560×1670 |
2YZS1860 |
6000×1800 |
2 |
3-100 |
400 |
65-550 |
22 |
6.95 |
7060×2560×1620 |
3YZS1860 |
6000×1800 |
3 |
3-100 |
400 |
65-550 |
22 |
7.70 |
7060×2560×1670 |
4YZS1860 |
6000×1800 |
4 |
3-100 |
400 |
65-550 |
30 |
8.70 |
7060×2560×1930 |
2YZS2160 |
6000×2100 |
2 |
3-100 |
400 |
81-720 |
22 |
8.48 |
7130×2990×1760 |
3YZS2160 |
6000×2100 |
3 |
3-100 |
400 |
81-720 |
30 |
9.24 |
7130×2990×1810 |
4YZS2160 |
6000×2100 |
4 |
3-100 |
400 |
81-720 |
30 |
10.45 |
7130×2990×1930 |
2YZS2460 |
6000×2400 |
2 |
3-150 |
400 |
100-810 |
30 |
12.35 |
7130×4121×1810 |
3YZS2460 |
6000×2400 |
3 |
3-150 |
400 |
100-810 |
37 |
13.85 |
7130×4121×1940 |
4YZS2460 |
6000×2400 |
4 |
3-150 |
400 |
100-810 |
37 |
15.60 |
7130×4121×2080 |
