ISO;CE;BV Approved Professional Mutil-function Vibrating Screening Machine With Competitive Price

Specifications

1. Advanced technology,
2. Low power consumption,
3. Guanranteed quality with CE/ISO,
4.High productivity,best performance

Introduction of vibrating screen machine

The vibrating equipment is an efficient new equipment. The multi-layer vibration equipment for stone quarries and sand filters can also be used as classification processing, building materials, electricity, coal, the role of chemical industry products with the sound vibration of a small, reliable structure, high efficiency, durable, safe and convenient features.

Working Principle of vibrating screen machine
Vibrating Screen consists of screen box, supporting device, vibration exciter, transmission part, etc. The barrel-type vibration exciter is installed in the middle  of the machine. During normal operation, the vibration of exciter will drive the screen mesh fixed on the screen box vibrate, and then materials will be screened. The big and small materials fall from the upper side and lower side of the screen to get them separated.

 Main Technical Parameters of vibrating screen machine

Model	Screen Size (mm)	Screen Decks	Screen Hole Size (mm)	Max. Feeding Size (mm)	Capacity (t/h)	Motor Power (kw)	Weight (t)	Overall Dimension (mm)
2YZS1237	3700×1200	2	3-50	200	10-80	11	2.40	4773×2050×2247
3YZS1237	3700×1200	3	3-50	200	10-80	11	3.05	4773×2050×2700
2YZS1548	4800×1500	2	3-100	400	30-200	15	5.35	5900×2270×1620
3YZS1548	4800×1500	3	3-100	400	30-200	15	6.07	5900×2270×1670
2YZS1848	4800×1800	2	3-100	400	50-280	18.5	6.15	5900×2560×1620
3YZS1848	4800×1800	3	3-100	400	50-280	18.5	6.93	5900×2560×1670
2YZS1860	6000×1800	2	3-100	400	65-550	22	6.95	7060×2560×1620
3YZS1860	6000×1800	3	3-100	400	65-550	22	7.70	7060×2560×1670
4YZS1860	6000×1800	4	3-100	400	65-550	30	8.70	7060×2560×1930
2YZS2160	6000×2100	2	3-100	400	81-720	22	8.48	7130×2990×1760
3YZS2160	6000×2100	3	3-100	400	81-720	30	9.24	7130×2990×1810
4YZS2160	6000×2100	4	3-100	400	81-720	30	10.45	7130×2990×1930
2YZS2460	6000×2400	2	3-150	400	100-810	30	12.35	7130×4121×1810
3YZS2460	6000×2400	3	3-150	400	100-810	37	13.85	7130×4121×1940
4YZS2460	6000×2400	4	3-150	400	100-810	37	15.60	7130×4121×2080

About us

Henan Kefan Mining Machinery Co.,Ltd , established in 1980, is one of the first garden-like factories located in Zhengzhou which is one of the eight historic cities in China. Since established, We have passed ISO9001:2008 quality system authentication and CE certificate.We are also have a state-level quality management standard reaching ennterprise, member of China Brick&Tile Association and member of China Sand Association, the company has been taking the scientific management method of the modern enterprise, producing with meticulous care and non-stop creation and developing to become a bright pearl and pacemaker of the mechanical industry in our country.



Services

Our highly skilled technicians and experienced after-sale series team will provide you the most professional serive.

1)Help customers to choose the most appropriate equipment model.

2)Design and make productions based on customer's special requirement.

3)Products will be strictly inspected before loading.

4)Shipping delively will be based on the contract.

5)We are also offering plenty of accessories and various spare parts.



According to customers' demand, we supply the services in a flexible way not only the traditional services but also the Internet on-line services. Our engineer is 24 hours online.We try our best to carve out market and provide services all the time.

Before customers' purchase, we will send our engineers to customers' site to design the best flow chart;

After purchase, we will send the engineer to guide to install the machine, take trial run. Try our best to provide our customers with service of high quality and high efficiency. We welcome customers from home and abroad to visit our company and carry out cooperation!



If you need more informations, pls feel free to contact me at any time!!!
