Specifications
mobile crushing station1.high efficiency
2.saving energy
3.CE,ISO,BV
China Mobile Crushing Station for Mining
This series of mobile crushing station is mainly used in metallurgy, chemical industry,building material,hydroelectricity for processing the materials that always need to be moved and transterred, especially for the mobile operation work, such as highway,railway,hydroelectric project. The customer could make different disposition according to the different kind, dimension of the raw materials and different requirements for the finished product.
Advantages of mobile crushing station:
1. Car motor and control box integration;
2. Car installation support,equipment,space efficient and convenient stationed;
3. High-performance crusher,large crushing ratio;
4. Steering traction axis, to facilitate road transport and venues depth;
5. Rational allocation according to the actual situation of the customer site.
Technical parameters of mobile jaw crusher:
| PP Mobile Jaw crusher plant | PP600 | PP750 | PP900 | PP1060 | PP1200 | PP1300 | |
| Shipping Size | Length(mm) | 8600 | 9600 | 11097 | 13300 | 15800 | 9460 |
| Width(mm) | 2520 | 2520 | 3759 | 2900 | 2900 | 2743 | |
| Height(mm) | 3770 | 3500 | 3500 | 4440 | 4500 | 3988 | |
| Weight(kg) | 15240 | 22000 | 32270 | 57880 | 98000 | 25220 | |
| Axle Load(kg) | 10121 | 14500 | 21380 | 38430 | 64000 | 14730 | |
| Tractor Weight(kg) | 5119 | 7500 | 10890 | 19450 | 34000 | 10490 | |
| Jaw Crusher | Type | PE400*600 | PE500*750 | PE600*900 | PE750*1060 | PE900*1200 | PE300*1300 |
| Material Inlet | 400*600 | 500*750 | 600*900 | 750*1060 | 900*1200 | 300*1300 | |
| Adjusting range of discharge hole | 40-100 | 50-100 | 65-180 | 80-180 | 95-225 | 20-90 | |
| Capacity(m3/h) | 10-35 | 25-60 | 30-85 | 70-150 | 100-240 | 10-65 | |
| Vibrating Feeder | Type | GZD8030 | GZD8030 | GZD9638 | GZD1149 | GZD1352 | GZD8030 |
| Capacity of bin | 3 | 4 | 7 | 10 | 10 | 3 | |
| Width of bin | 2200 | 2500 | 3000 | 3000 | 3000 | 2200 | |
| Belt Conveyor Type | B500*6 | B650*7 | B800*8 | B1000*11 | B1200*13 | B800*7 | |
Technical parameters of mobile cone crusher:
| PP mobile cone crusher plant | PP900SMHS | PP1200SMHS | PP1750SMHS | PP2200SMHS | |
| Shipping Size | Length(mm) | 10000 | 11200 | 11800 | 12300 |
| Width(mm) | 2743 | 2743 | 2840 | 2900 | |
| Height(mm) | 4200 | 4200 | 4200 | 4200 | |
| Weight(kg) | 28400 | 30500 | 22400 | 48700 | |
| Axle Load (kg) | 15500 | 16300 | 14300 | 31100 | |
| Tractor Weight(kg) | 12900 | 14200 | 8100 | 17600 | |
| Cone Crusher Type | PY900 | PY1200 | PY1750 | PY2200 | |
| Max.Feeding Size | 50-110 | 50-145 | 85-215 | 100-300 | |
| Adjusting range of discharge port | 10-32 | 15-50 | 20-50 | 20-60 | |
| Screen Type | 3YK1235 | 3YK1545 | 4YK1860 | 4YK2160 | |
| Belt Conveyor Type | B650*8 | B800*8 | B1000*8 | B1200*8 | |
Technical parameters of mobile impact crusher:
| PP mobile impact crusher plant | PP1010PFS | PP1210PFS | PP1214PFS | |
| Shipping Size | Length(mm) | 10800 | 12200 | 12500 |
| Width(mm) | 2480 | 2743 | 2900 | |
| Height(mm) | 4170 | 4200 | 4200 | |
| Weight(kg) | 28800 | 31500 | 39600 | |
| Axle Load (kg) | 17500 | 17200 | 22100 | |
| Tractor Weight(kg) | 11300 | 14300 | 17500 | |
| Impact Crusher Type | PF1010 | PF1210 | PF1214 | |
| Material Inlet(mm) | 400*1080 | 400*1080 | 400*1430 | |
| Screen Type | 4YK1235 | 4YK1545 | 4YK1848 | |
Certification:
