China hot sale high quality rotary vacuum dryer
- 100 Set / Sets per Month
- nearest port
- T/T Credit Card
Product Details
Condition: | New | Type: | Rotary Drying Equipment | Place of Origin: | Henan, China |
Brand Name: | Henan Kefan | Model Number: | SD500,SD1000,SD2000,SD3000 | Voltage: | 380v |
Power(W): | 30kw | Dimension(L*W*H): | Diameter: 0.8-4.2 m, length: 6-60m. | Weight: | 1000kg-1000t |
Certification: | BV/CE/ISO | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
China hot sale high quality rotary vacuum dryer
1. Introduction
Rotary dryer is mainly used for drying materials with some moisture and granularity in ore beneficiation, building material, metallurgy and chemical department. Rotary dryer has high adaptability to the materials so that it can be used for drying all kinds of materials, and in addition, the operation of this equipment is simple and reliable, for this reason, it gets wide application.
2.Operational Scene
The heat source of the rotary dryer comes from the combustion device and this dryer uses co-current heating method, so that when the materials to be dried go into the cylinder from the feeding box or feeding chute, they are pushed back by the spiral lifting board. Since the rotary dryer is obliquely installed, the materials flow to the lower end of the machine under the gravity and the rotation of the machine, and on the other hand, the materials are repeatedly lifted by the lifting board to the higher end and then spread down constantly, so that the materials will form a even curtain inside the cylinder and conduct heat exchange with the hot air inside the cylinder. Since the materials constantly spread and the water contained in them will be dried, thus achieving the aim of drying.
Process:
Product parameters:
| Capacity(t/h) | Main motor | Main gear box | Weight(t) | ||
Power(kw) | Model | Model | Speed reduction ratio | |||
1.2*10 | 2.5 | 7.5 | Y160M-R3 | ZL50-16-I | ----- | 13.5 |
1.5*12 | 3.3-4.9 | 10 | Y160L-6-B3 | JZQ500-III-2F | ----- | 18.9 |
1.5*15 | 4-6 | 18.5 | Y200L1-6 | JZQ500-III-2F | ----- | 21 |
1.8*12 | 4-6 | 18.5 | Y160L-6 | ZQ50-16II-2 | 16.46 | 22.83 |
2.2*12 | 7-12 | 18.5 | Y200L7-6 | JZQ650-III | 31.5 | 37.6 |
2.2*14 | 7-12 | 22 | Y200L7-6 | JZQ650-III | 31.5 | 40 |
2.2*16 | 12 | 30 | Y225M-6 | JZQ750-III | 31.5 | 45 |
2.4*14 | 12 | 30 | Y250M-6 | JZQ750-III | 31.5 | 51 |
2.4*18 | 10-13 | 37 | Y250M-6 | ZL85-13-I | 27.16 | 54 |
2.4*20 | 10-14 | 37 | Y250N-6 | ZL85-13-I | 27.16 | 54.14 |
3*20 | 25 | 55 | Y250M-4 | ZL100-16-I | 41.52 | 78 |
3*25 | 32-36 | 75 | YR280M-4 | ZL100-16-I | 41.52 | 104.9 |
Certification:
Contact Us
- Henan Kefan Mining Machinery Co., Ltd.
- Contact namejenny wang
- Phone0086-0371-67996718
- AddressXushui Industry Zone, Zhengzhou, China Zhengzhou,Henan
