15 Years Experience CE Certificate Chicken Manure Dryer
Product Description
Please confirm with us the capacity and moisture inside the chicken manure,according to your required we will suggest you exact machine with best offer,pictures,vedios,technical parameters as soon as possible.
Work principle of Chicken manure dryer:
The complete sets of chicken manure dryer equipment mainly is composed of the crushing drum dryer, burning furnace, feed spiral,output spiral, pipeline, dust collector, airlock, air induced fan, electric control cabinet and othercomponents.
Humidity materials are conveyed from the feed screw directly into the chicken manure dryer, raised by the drum wall panels repeatedly, and scattered by the crushing blow dispersion devices.
Materials and the negative high-temp media are combined sufficiently to complete heat and mass transfer process of chicken manure dryer. As the result of the drum wind angle and the induced air, the feed materials move slowly, and discharged from the spiral after drying, the exhaust gas handled by the dust precipitator, venting to the atmosphere.
Invironmental protection equipment of chicken manure dryer:
The chicken manure dryer equipment uses down stream drying process, especially suitable for fast drying the humidity materials which need to preserve nutrition, for example, the drying of fresh chicken manure can achieve the purposes of drying, sterilization, deodorant and preservation of nutritional.
The chicken manure dryer is equipped with high-speed rotating drum of crushing devices, which increases the contact area between material and drying medium, the internal unique equipment design, makes materials difficult to adhere to the drum wall panels and parade.
The complete chicken manure dryer machine has the effects of heat preservation, good sealing performance, and the fact that the thermal efficiency considerably
Component of chicken manure dryer:
Feeder machine
Discharge machine
Temperature detector
Chicken manure dryer cylinder
Roller ring
Carrier roller
Big gear
Transmission parts(motor,reducer,small gear)
Cyclone which is collect the dust out from the dryer
Fan
Connection pipes
Furnace
Fire tube
The advantage about chicken manure dryer:
No pollution and protect environmental.
Fully automatic continuous working.
Chicken manure dryer made by Q345 Manganese steel.
Temperature and speed adjusted.
No spare parts as the dryer is low speed rotation.
High efficiency.
Chicken manure dryer whole line only need two or three people to control.
Certification of chicken manure dryer:
We Don't Just Sell 15 Years Experience CE Certificate Chicken Manure Dryer ,We build Solutions.Please never hesitate to contact us,
we will be pleased to submit our offer together with our solution.
