Efficiency Hot Saling High Standard Impact Crushing Machine With Best Price
US$ 1,000 - 9,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Impact Crusher
Application:
mining, cement, coal, metallurgic material, construction material, ect
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2015 Newest Design Hot Saling High Standard Jaw Crushing Machine With Best PriceUS$ 1,000 - 999,999MOQ: 1 Set -
Best Price Hot Saling High Standard Hammer Crushing MachineUS$ 1,000 - 99,999MOQ: 1 Set
-
Good Quality Hot Saling High-efficiency Complex Crusher With Best PriceUS$ 1,000 - 99,999MOQ: 1 Set
-
2013 Newest Design Hot Saling High Standard Roll Crusher With Best PriceUS$ 1,000 - 99,999MOQ: 1 Set
-
Efficiency Good Quality Hot Saling DL1580(C) Compound Cone Crusher (hydraulic) With Best PriceUS$ 1,000 - 99,999MOQ: 1 Set
Condition
New
Type
Impact Crusher
Application
mining, cement, coal, metallurgic material, construction material, ect
Motor Type
AC Motor
Power(W)
132kw
Capacity(t/h)
100-180t/h
Place of Origin
Henan, China
Brand Name
Henan kefan
Model Number
PF1214
Dimension(L*W*H)
2580*2400*2810mm
Weight
19t
Certification
BV;CE;ISO
Warranty
1 year, 2 years
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Impact Crushing Machine1)Features:energy saving,high efficiency,easy operation,etc.
2)Capacity:100-180t/h;
3)CE/ISO Approved
Descriptions:
Impact crusher is new product designed by our company after absorbing the advanced technology home and abroad. This kind of crusher can crush many kinds of materials with max feed size less than 500mm and crushing strength less than 350 Mpa. Its features are high ratio of crushing, high efficiency of crushing, easy to maintenance, etc.
The final products are with cubic shapes and are the ideal secondary and tertiary crushing equipments for construction the highway and water and electricity construction. In addition, impact crushers are more suitable to process granite, limestone, bank gravel etc in the area of highway construction, water conservancy project and architecture.
Characteristics:
- Hammer is made of high chrome; liner board is made of wearable materials;
- Specially designed tooth impact plate;
- More suitable for crushing hard rock, high efficiency, low consumption;
- Final products is cubic, discharge opening is adjustable;
- Make the crushing flow chart simple.
Advantages:
- Advanced design;
- High reduction ratios;
- The below bar with high chrome;
- Hydraulic or manual open switch;
- Impact with special shape;
- Excellent,stress-free,cubical-shape products;
Structures:
Technical parameters:
| Model | Specification(mm) | Feeding Size(mm) | Max Feed Size(mm) | Capacity(t/h) | Motor Powder (kw) |
| PF-0607 | 644*740 | 320*770 | 100 | 10-20 | 30 |
| PF-0807 | 850*700 | 400*730 | 300 | 15-30 | 30-45 |
| PF-1008 | 1000*800 | 400*830 | 300 | 30-50 | 37-55 |
| PF-1010 | 1000*1050 | 400*1080 | 350 | 50-80 | 55-75 |
| PF-1210 | 1250*1050 | 400*1080 | 350 | 70-120 | 110-132 |
| PF-1212 | 1250*1250 | 400*1300 | 350 | 100-150 | 132-160 |
| PF-1214 | 1250*1400 | 400*1430 | 400 | 130-180 | 160-200 |
| PF-1315 | 1320*1500 | 860*1520 | 500 | 160-250 | 180-260 |
| PF-1320 | 1320*2000 | 860*2030 | 500 | 300-350 | 300-375 |
