Hot Selling Durable Straw Baler Compress Machine for Agricultural

Hot Selling Durable Straw Baler Compress Machine for Agricultural photo-1
Hot Selling Durable Straw Baler Compress Machine for Agricultural photo-2
US$ 5,000 - 5,000 MOQ: 2 Sets
Key Specifications
Get Latest Price
Type:
Other
Operating Speed:
2-5km/h
Condition:
New
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao/Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Type Other
Operating Speed 2-5km/h
Condition New
Place of Origin Henan, China
Brand Name kefan
Model Number kf70
Application Hay
Dimension(L*W*H) 3320*2880*2800
Weight 2000 kg
Certification CE ISO
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas

hot selling  durable straw baler compress machine for agricultural



[Production capacity]:60-70 bundles / hour

[Advantages]Straw baler machine belong to automatic straw press baler. The machine through stroke switch match with four hydraulic cylinder complete straw crushing and boundling.Artificial only need receiving bag, bagging, tying the bag.
[Applications]:The machine is suit to process corn straw, wheat straw, straw, cotton, wool, waste paper, waste box, waste paper plates, yarn, tobacco leaf, plastic, cloth, weave bags, Knitted cashmere, hemp, hemp bag, tops, hairball, cocoon, silk, hops, mak chai, grass, waste plastic bage and all the other light bulbs and loose materials.

Product Details

Straw baler machine consist of collecting material box, pressing box, discharging port, main press head, side press head, push package press head, hydraulic cylinder, hydraulic valve, electric appliances and other spare parts.

Operation method:

Main cylinder transverse push press--side cylinder vertical direction press--push package press head push mass block to package bag. Each part return to original position and continue for the next working process. The whole process at one go, at the same times can switch to semi-automatic, manually. Improved packing efficiency greatly.

hot selling durable straw baler compress machine for agriculturalhot selling durable straw baler compress machine for agriculturalhot selling durable straw baler compress machine for agricultural

Property advantages:

All the machine type adopt hydraulic driving, can select manually or PLC automatic control operation.

Discharging method have turning bag, pushing bag(side pusing and front pushing) or manual take package(packing) and other different methods.

Installation no need footbolts, at the place without power resource can adopt diesel engine as power.

Press force frome 63tons to 400 tons have ten grades for user to select. Production efficiency from 4ton/working shaft to 40tons/working shaft.

Press chamber size and output mass block size can be design according to user requires.

Technical Parameters

Model KF-7 Matched power(kw) 15
Hydraulic oil pump displacement(L/min) 63 Bundling ability(Bundles/h) 60-70
Grass bundle specification(mm) 240*360*700 Products density(kg/m3) 300-400
Oil cylinder nominal pressure(pa) 20 Oil consumption(kw.h/t) ≤3
The whole machine size(mm) 3320*2880*2800 The whole machine weight(kg) 2000
