Yineng China YN860 Skid Steer Loader Pallet Fork
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Yineng China YN860 Skid Steer Loader
-
Hot Sale YN865 Small Skid Steer Loader Adopt Xinchai Engine 0.5cbm Bucket Capacity
-
Hot Sale YN860 Small Skid Steer Loader Adopt Xinchai Engine 0.5cbm Bucket Capacity
-
Hot Sale Small YN845 Skid Steer Loader Adopt Xinchai Engine 0.4cbm Bucket Capacity
-
Skid Steer Loader(1000kg+80hp+0.5m3+Imported Hydraulic System+Closed Cabin)
-
World Class Brand Shan Dong Loader Yineng China YN845 Skid Steer Loader
Product Details
| Place of Origin | Shandong, China | Brand Name | YN (yineng)LN(Luneng) | |
| Model Number | YN860wheel Loader | After-sales Service Provided | Overseas service center available |
Product Description
ISO9001:2008 certificate
Our workshop:
OEM of Liu Gong,Foton Lovol and Power Plus
YN 860 Common model:
YN860 skid steer loader technical specifications:
1.Chinese Xinchang diesel engine 498
2.USA Eaton/Italy B.P brand hydraulic pump
3.USA Eaton brand hydraulic motor
4 Mechanical control system
5.Open cabin
6.Hydraulic brake
7.Bobcat type quick coupler
Item | Description | Item | description |
Rated operating capacity(kg) | 850 | Hinge pin height (mm) | 2920 |
Tipping load (kg) | 1700 | Total height (mm) | 2080 |
Bucket capacity(m3) | 0.4-0.5 | Length with bucket (mm) | 3440 |
Hydraulic pump flow (L/min) | 75 | Length without bucket(mm) | 2630 |
Engine power (hp) | 60 | Width with bucket (mm) | 1820 |
Weight(kg) | 3150 | Track width (mm) | 1500 |
Max travel speed (km/h) | 12 | Wheelbase (mm) | 991 |
Grade ability | 20 | Ground clearance (mm) | 205 |
Tire | 12-16.5 | Dumping angle | 40 |
Fuel/hyd oil capacity (L) | 60/60 | Dumping height (mm) | 2330 |
Height at maximum extension | 3690 | Maximum reach (mm) | 710 |
YN860 skid steer loader Quotation:
FOB Qingdao,
1.Original hyundai engine +$1400
2.Original perkins engine +$3700
3.Close cabin +$300
4.Air condition +$750
5.Heater +$100
Packing:
2units/20' container
4units/40' container
Delivery time: 20 days
Guarantee: 1 Year
left style='text-align:left;line-height:15.6pt; mso-line-height-rule:exactly;mso-layout-grid-align:none;text-autospace:none'>4 units/40' container
Delivery time: 20 days
Guarantee: 1 Year
