ISO9001:2008 certificate
Our workshop:
OEM of Liu Gong,Foton Lovol and Power Plus
YN 926 Mining Use Series Common model:
YN926
LR4B3-G92X1A-U2
Adopt Dongfanghong YITUO diesel engine is adopted, with strong power.
Smoke purification, the smoke volume decrease greatly, green environmental protection
Applying hydrodynamic transmission technology, single stage, 3 elementstorque converterowns simple structure and high reliability.
Single pump, split flow working hydraulic system makes lower consumption and excellent performance
Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage
Load sensing fully hydraulic steering system makes operation easy.
Air over hydraulic brake system; Caliper disc brakes.
Working device with automatically levelling ability at high position.
Integral, luxury instrument board.
New, luxury cabin.
Main specifications
Items |
Specfication |
Items |
Specfication |
|
Bucket capacity |
0.7m3 |
Min. turning radius
|
4750mm |
|
Rated load |
2000Kg |
Steering angle |
About 35° |
|
Dumping height |
2230mm |
Min. ground clearance |
320mm |
|
Dumping distance |
920mm |
Wheel base |
2350mm |
|
Boom lifting time |
5S |
Tread |
1500mm |
|
Total cycling time |
9S |
Rated power
|
60KW/2400rpm |
Max. speed |
25Km/h |
Tyre specifications |
16/70-20 |
|
Max. breakout force |
55KN |
Overall dimensions |
5760×1910×2370 |
|
Max.drawing force |
45KN |
Operating weight |
6000Kg |
|
Max. Gradeability |
30° |
|
|
5. Others:
(1) Packing: within 1 x 40HQ container
(2) Delivery time: 40 days
(3) Guarantee Period: One year
(4) Offer Validity: 30 days
