ISO9001:2008 certificate
Our workshop:
OEM of Liu Gong,Foton Lovol and Power Plus
Features:
Using the Germany champion’s disc technique vertical cutting platform, working width 2.4meters
The engine by Yuchai engine, output power of 190 horsepower, reliable quality, fuel consumption is small;
Free switching between 4WD walking and 2WD walking modes, improve the machine environment adaptability.
Adopt the operating system of electro-hydraulic control and CVT, electronic header, which is convenient for driver to operate;
Cast spout is in the way of rotating turbine, can be controlled wirelessly and remotely by handle;
Large capacity dump hopper, easy for the car-following operation;
Adjust the cutting length of the materials in multi-polar. The unique grain crushing and scrubbing device, straw rubbing rate is more than 95%, grain crushing rate is more than 90%.
2.Main Specifications:
Items |
Parameters |
Operation way |
Auto-run unlevel harvest |
Cutting table type |
vertical cylinder |
Operation Range |
2400mm |
Operation speed |
4-8km/h |
Efficiency |
20-60T/h |
Cutting Length |
7-50mm(adjustable) |
Loss rate |
≤3% |
Min cutting height |
≤150mm |
Engine Power |
140kw(190hp) |
Dimension |
7100*2850*4730mm |
Overall weight |
6900kg |
Remark: Heavy chassis for standard
3. Quality certificate:
(1)CE Approved.
(2)Obtained the certificate of ISO9001:2008.
(3)Manufacturing license number:
4. Quotation:
(Standard model with FOB Qingdao Port)
5. Others:
(1) Packing: 1 unit naked within 1 x 40HQ container
(2) Delivery time: 40 days
(3) Accidental benefits: Customers can purchase wearing parts according to the parts list we offered.
(4) Guarantee Period: One year
(5)Offer Validity: 30 days
