YN 959 Pay Loader China Shan Dong Taian LN Heavy Loader

Name: YN 959 Pay Loader China Shan Dong Taian LN Heavy Loader
Brand: YN (yineng)LN(Luneng)
SKU: 141006846
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

YN (yineng)LN(Luneng)

Model Number:

YN959wheel Loader

Shandong Yineng Heavy Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name YN (yineng)LN(Luneng)

Model Number YN959wheel Loader

After-sales Service Provided Overseas service center available

ISO9001:2008 certificate

1. Features:

* Shangchai Caterpillar tech SC11CB220G2B1 engine is adopted, large torque backup and strong power.

*Hangzhou Advance Gear Group WG180 torque converter and fix-shaft gearbox, with ZF technology.

*Electro-hydraulic control, 4 forward and 3 reverse,

*Single lever pilot control system makes operation easy and comfortable.

*Strengthened axles owns large bearing capacities and high reliability.

*Twin pump merging hydraulic system makes lower consumption and excellent performance.

*The coaxes flow-amplified, hydraulic compensated steering makes operation easy and performance reliable.

*Both travel system and working hydraulic system are forced-cooled, improving the efficiency obviously.

*Air over hydraulic brake system; eight caliper disc brakes.

*Air break control, expand hoof type parking brake and emergency brake.

*Large space articulated frame makes operation and traveling stable.

*Working device with automatically leveling ability at high position.

*Main articulated points take sealed, lubricated, dust-proof layers, which owns good durability.

* Integral, luxury instrument board.

* New, luxury cabin

2.Main Specifications:

Item	Specification	Item	Specification
Bucket capacity	3m³	Min. turning radius(outside of rear wheel)	6360mm
Rated load	5000kg	Steering angle	35°
Dumping height	3100mm	Min. ground clearance	478mm
Dumping reach	1280mm	Wheel base	3200mm
Max. speed	6s	Wheel tread	2250mm
Max. breakout force	38km/h	Rated power	162kW/2200rpm
Max. breakout force	170kN	Tyre	23.5-25
Max. drawing force	150kN	Overall dimensions	796030703490mm
Max. grade ability	28°	Operating weight	17000kg
