Help CenterZL20 YNwheel Loader CE Approved SHAN DONG Yineng YN 926 Loader 0.7cbm 2ton k Series Loader
Related Products
-
926 Wheel LoaderNegotiableMOQ: 1 Set -
ZL20 With CE;ISO Provided YN 926 for SaleNegotiableMOQ: 1 Set
-
Yineng Loader High Quality SHAN DONG Yineng YN 926 Loader 0.7cbm 2ton k Series LoaderNegotiableMOQ: 1 Set
-
YIneng Wheel Loader YTO CE Approved SHAN DONG YN 926 Loader 0.7cbm 2ton k Series LoaderNegotiableMOQ: 1 Set
-
First Class CE Provided 2 Ton Front Wheel Loader for Sale YN926 Adopt YTO Engine 1.1cbm Bucket CapacityNegotiableMOQ: 1 Set
ISO9001:2008 certificate
Our workshop:
OEM of Liu Gong,Foton Lovol and Power Plus
YN 926 Mining Use Series Common model:
YN926
LR4B3-G92X1A-U2
Adopt Dongfanghong YITUO diesel engine is adopted, with strong power.
Smoke purification, the smoke volume decrease greatly, green environmental protection
Applying hydrodynamic transmission technology, single stage, 3 elementstorque converterowns simple structure and high reliability.
Single pump, split flow working hydraulic system makes lower consumption and excellent performance
Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage
Load sensing fully hydraulic steering system makes operation easy.
Air over hydraulic brake system; Caliper disc brakes.
Working device with automatically levelling ability at high position.
Integral, luxury instrument board.
New, luxury cabin.
Main specifications
Items |
Specfication |
Items |
Specfication |
|
Bucket capacity |
0.7m3 |
Min. turning radius
|
4750mm |
|
Rated load |
2000Kg |
Steering angle |
About 35° |
|
Dumping height |
2230mm |
Min. ground clearance |
320mm |
|
Dumping distance |
920mm |
Wheel base |
2350mm |
|
Boom lifting time |
5S |
Tread |
1500mm |
|
Total cycling time |
9S |
Rated power
|
60KW/2400rpm |
Max. speed |
25Km/h |
Tyre specifications |
16/70-20 |
|
Max. breakout force |
55KN |
Overall dimensions |
5760×1910×2370 |
|
Max.drawing force |
45KN |
Operating weight |
6000Kg |
|
Max. Gradeability |
30° |
|
|
5. Others:
(1) Packing: within 1 x 40HQ container
(2) Delivery time: 40 days
(3) Guarantee Period: One year
(4) Offer Validity: 30 days
Shandong Yineng Heavy Industry Co.,Ltd (Taian Luneng Machinery Co.,Ltd) was found in 1999, is a collection of development and production as one of the engineering machinery manufacture enterprise. It is Situated at the foot of the world famous Mount.Tai, the main products are YN series wheel loaders, with more than 20 different models loaders in total. With 10000 units of annual production capacity, YINENG has passed the ISO9001:2000 international quality management system certification and assessment of State Engineering Machinery Quality Supervision & Testing Center. It also obtained the Special Equipment Production License and a member of China Machinery Council as well. The company expanded the scale in 2010 again and established Shandong Yineng Heavy Industry Co.,Ltd, It also has “Taian Yineng Hydraulic Co., Ltd ”, “Taian Luneng Import & Export Co., Ltd”, “Taian Luneng Trading Co., Ltd” and “Taian Luneng Frame Co., Ltd” as branches.
Always following the philosophy of “Prosper enterprise with super quality products; to create YINENG brand”, YINENG considers products quality as the life of enterprise and control the quality strictly to strive to fine products. Customers’ needs as the direction of products development and “to build the top brand of small loader” as striving target. YINENG has won wide market with excellent products, better service and reasonable price. YINENG products are not only popular in more than 20 domestic provinces and cities, but also exported to Kazakhstan, Indonesia, UAE, Saudi Arabia, Syria, Iran, Brazil, Venezuela, Nigeria, South Africa, Australia, etc.
Agent Supporting Services
Technical Guidance:
1. Provide the video for technical guidance
2. Factory send technician to agent country for technical guidance three times per year
3. Agent also could send technician to our factory to learn technology
Training Support: 1. Provide the video for training
2. Factory send technician to agent country for training three times per year
3. Agent also could send technician to our factory to learn technology
Marketing Support:Factory will provide any way to help the agent to promote, such as fair....
After-sale Service:
Factory provide one year or 2000 hours after sales service in worldwide, Agent shall provide local technicians and staffs to satisfy the management , operation and training of after sale service, and provide workshop, warehouse, office and other facilities to support a sustained after sale service.
Commission & Profits: Agent could get 3% to 10% commission according to the size of the profit.
