0.7 Cbm Wheel Loader

Name: 0.7 Cbm Wheel Loader
Brand: yinenYINENG
SKU: 141006352
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

yinenYINENG

Model Number:

YN918

Shandong Yineng Heavy Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name yinenYINENG

Model Number YN918

Place of Origin Shandong, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 5520*1800*2650MM

Rated Load 1500kg

Certification GOST,CE,ISO

Warranty 1 YEAR

After-sales Service Provided Overseas service center available

Specifications

small wheel loaer,Bucket capacity0.7m3, Rated load 1500kg, Dumping height 2700mm, Rated Power 38kw

 Small wheel loaer,Bucket capacity0.7m3, Rated load 1500kg, Dumping height 2700mm, Rated Power 38kw 1-      FEATURES:

* Adopt Jiangsu Changchai four cylinder diesel engine.

*Hydrodynamic transmission technology and separated structure make high reliability and easy maintenance.

* Controlled by flexible shaft, hydraulic power shift gearbox with 2 forward and 2 reverse gears makes operate easy.

* Single pump, split flow working hydraulic system makes lower consumption and excellent performance.

* Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage;

* Load sensing fully hydraulic steering system makes operation easy.

* Air over hydraulic brake system; Caliper disc brakes.

* Working device with automatically levelling ability at high position.

* Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.

* Integral, luxury instrument board. New, luxury cabin.

2- SPECIFICATIONS:

Item	Specifications	Item	Specifications
Bucket capacity	0.7 m³	Min. turning radius (outside of rear wheel)	4200mm
Rated load	1500 kg	Steering angle	35º (L/R)
Dumping height	2700 mm	Min. ground clearance	250mm
Dumping reach	860 mm	Wheel base	2150mm
Boom lifting time	4.5 S	Tread	1400mm
Total cycling time	9 S	Engine model	4L68
Max. speed	19km/h	Rated power	38kW/2400rpm
Max. breakout force	46 kN	Tyre	16/70-16
Max.drawing force	33 kN	Overall dimensions	552018002650mm
Max. Gradeability	28°	Operating weight	4500kg
