9YFQ-1.9 Square baler
This model of square baler can automatically pick up hay laying in the field. After conveying, feeding, compressing and bundling, the loose forage hay will be bundled into a regular square bale.
Features:
* Produce high density and strong bales.
* Bales of regular shape, easy to store and transport
* Easy to operate, one tractor driver is enough
* Wide scope of application: It is suitable for various native pasture, planting pasture and farm, also it is suitable for stationary work.
Technical Parameter:
Item | 9YFQ-1.9 | |
Dimension | L*W*H | 4975*2550*1710mm |
Weight | kg | 1500 |
Tyre | Size | 10-15 9.00×15.3 |
Pressure | 300Kpa | |
Pick up device | Working width | 1962mm |
Cylinder rotary speed | 138 r/min | |
Quantity of tine rod and tine | 3 pcs,42 pcs | |
Distance between tines | 66mm | |
Controlling system of tines moving trajectory | Directional wheel system | |
Overload protection | Belt slip | |
Tracing wheel | 2 pcs(one for each side) | |
transmission | Chain transmission 08B-1-100 | |
Spiral conveyor | Auger Diameter | 330mm |
Rotary speed | 313 r/min | |
Overload protection | Belt slip | |
Transmission | Chain transmission 08B-1-100 | |
Intake system | Structure | Crank and roller mechanism |
rated working frequency of feed fork | 100times/min | |
Quantity of feed fork | 4 pcs | |
Transmission | Chain transmission 12A-1-116 | |
Overload protection | Shear bolt | |
Piston | Rated speed of moving back and forth | 100 times / min |
Stroke length | 550mm | |
Baling chamber | Dimension of cross section | 355×440mm |
Length of bale | 30~120cm | |
Bales density controlling | Spring load density controller | |
Baling mechanism | Spindle speed | 100 r/min |
Transmission | Chain transmission 10A-1-164 | |
Overload protection | Shear bolt | |
Rope box capacity | 4 rolls | |
Matched power | horsepower | Tractors above 35hp |
Rotary speed of PTO | 540 r/min | |
