Universal Lathe Machine for Sale CY-6140/1000

Universal Lathe Machine for Sale CY-6140/1000 thumbnail-1
Universal Lathe Machine for Sale CY-6140/1000 photo-1
US$ 3,000 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
CNC
Contact Supplier Request Quote Chat Now
Guangxi Xiashi Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Horizontal
CNC or Not CNC
Automatic Grade Automatic
Max. Swing Diameter 400mm
Place of Origin Guangxi, China
Brand Name XiaShi
Model Number CY-6140/1000
Power(W) 7.5kw
Certification ISO9001,CE
After-sales Service Provided Engineers available to service machinery overseas



Product Description



SPECIFICATION

CY-6140

Swing over bed

400mm

Swing over cross slide

220mm

Width of bed

390mm

Length of work piece (max)

1000mm

Spindle nose

C6

Taper of spindle center

M6

Spindle bore diameter

52MM

Spindle speed

9-1600rmp

Max. output torque of spindle

1500N.m

Range of longitudinal feed

0.028-6.43mm/rev

Range of transverse feed

0.12-2.73mm/rev

Lead screw pitch

12mm(metric system) 2TPI (inch system)

Lead screw diameter

40mm

Metric threads

0.5-224mm(48 pitches)

Inch threads

72-1/8TPI (46 pitches)

Module threads

0.5-112mm(42 pitches)

Diameter pitch threads

56-1/4DP (45 pitches)

Cross slide travel(max.)

320mm

Top slide travel (max.)

145mm

Section specification of tool post

25x25mm

Longitudinal rapid traveling speed

4.5m/min (50HZ) 5.4m/min (60HZ)

Transversal rapid traveling speed

1.9mm/min(50HZ) 2.3m/min(60HZ)

Morse taper of tailstock center

M5

Max. travel of tailstock quill

150mm

Tailstock quill diameter

75mm

Main motor

7.5kw

Rapid travel motor

250w 1360rpm

coolant pump motor

90w 25L/min





Universal lathe machine for sale CY-6140/1000



 Workshop

Universal lathe machine for sale CY-6140/1000Universal lathe machine for sale CY-6140/1000Universal lathe machine for sale CY-6140/1000





FAQ



1.  Payment

What are the terms of payments you offer?

We accept payment of T/T, LC and Western Union etc

2.  Shipment

How long will it take to deliver goods?

We will deliver the goods within 10 days for spare parts, we will deliver the goods within the deadline which both parties agree.

3.  What kind of packaging you offer?

Normally in Plywood case or nude package,to make sure all goods in a good condition.

4.  What kind of transportation methods you offer?

We always transport by sea or by air, we will confirm freight with buyers' prior delivery.

5.  How about the insurance during transportation? How to deal with the responsibility?

Buyers should take the full responsibility for shortage of goods if the goods are checked

by any custom during transportation. During transportation, if goods are missed because of

having been detained by custom in China, all loss thus occurred should be borne by us; if

missing or detained of goods are occurred in other country except China, all loss should be

borne by buyers.



Our Services



1. 24-hours technical support by E-mail or telephone

2. Provide extra accessories for the machine

     Also provide service of make program according to your drawings

    Customized or special design is OK.

3. All of our products’ warranty period for 12 months.

4. Man-made destroy will be exception

5.We can supply the materials or tech support to our customers to help them fix the problems.

  We will pay the delivery charge if the repair, return or replacement cases happen.



Contact

1.Our working time: 8:30am~5:30pm

2. All inquiries will be replied within 24 hours, So please feel free to send us your

inquiry.

3. when our trade manager is off line, please feel free to leave a message, and tell us the

products with model you are interested in, and your E-mail address, we will reply to you within

24 hours.
