Gap Bed Lathe Machine for Sale C6140D

Name: Gap Bed Lathe Machine for Sale C6140D
Brand: Xiashi
SKU: 140990486
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangxi, China

Brand Name:

Xiashi

Model Number:

C6140D

Guangxi Xiashi Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangxi, China

Brand Name Xiashi

Model Number C6140D

Condition New

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Features

Gap-bed Lathes C6240D*500mm 750mm 1000mm 1500mm

1.High quality casting body.

2.Precision ball screws.

3.Hardened and ground bed way coated with.

4.Turcite-B

Specification

Specification	Gap C6232D	straight C6132D	Gap C6236D		straight C6136D	Gap C6240D		straight C6140D
Center height	160mm		180mm			200mm
Max .Swing over bed	320mm		360mm			400mm
Max .Swing over carriage	190mm		190mm			210mm
Max .Swing in gap	520mm	——	540mm		——	560mm		——
effective gap length	200mm	——	200mm		——	200mm		——
Max .length of work piece	750mm or 1000mm
Width of bed	310mm
Spindle taper	MT6
Thru-hole spindle	52mm
Spindle speed	30-1600r/min (12steps)
Cross Travel	240mm
Compound Travel	140mm
Tailstock center sleeve travel	90mm
Tailstock center sleeve taper	MT4
Spindle motor	3/4kw
Range of metric thread(kinds)	0.45-20mm (30kinds)
Range of inch thread(kinds)	80-1.75 n/1’’
Longitudinal feed per spindle rev.	0.039-1.1mm
Cross feed per spindle rev.	0.018-0.55mm
Overall dimensions for 750mm	2000×1130×1540mm
Overall dimensions for 1000mm	2250×1130×1540mm
Net weight of 750mm	1400kg			1500kg			1700kg
Net weight of 1000mm	1500kg			1600kg			1800kg
