Home > Manufacturing & Processing Machinery > Machine Tools > Grinding Machine > KENT USA Disc Brake Surface Grinding Machine KGS150

KENT USA Disc Brake Surface Grinding Machine KGS150

KENT USA Disc Brake Surface Grinding Machine KGS150 thumbnail-3

KENT USA Disc Brake Surface Grinding Machine KGS150 photo-1

KENT USA Disc Brake Surface Grinding Machine KGS150 photo-2

KENT USA Disc Brake Surface Grinding Machine KGS150 photo-3

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Surface Grinding Machine

CNC or Not:

Normal

Contact Supplier Request Quote Chat Now

Guangxi Xiashi Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Surface Grinding Machine

CNC or Not Normal

Model Number KGS150

Voltage 380v

Power(W) 1.1kw

Dimension(L*W*H) 1100*1020*1945mm

Weight 620kg

After-sales Service Provided Engineers available to service machinery overseas

Product Description

1.table ball orbit using steel materials and through hardening processing, high precision steel ball, wear resistance, easily move, can greatly improve the work efficiency .

2. double "V" slide before and after , through precision shovel flower, not only sliding smoothly and wearresisting, but also with teflon paste plastic leather ,is durable,good accuracy

maintaining, flexible operation of portable.

Manual working Table using rope drive .

3. spindle motor using no vibration, low noise ABB brand motor.

4, the spindle is sleeve type of high precision, adopt four with P4 level precision bevel angle

rolling bearings, the bearing brand is NSK of Japan, after strict measurement choice preloading, assembled in the temperature control room, and cooperate with the completely waterproof

labyrinth design, in order to ensure the service life of the bearing, and the roughness of grindingsurface.

Technical parameters

Parameters		Unit	KGS150
Working Surface of Table		mm	150×450 (5.9"×17.7")
Max.Table Travel		mm	480
Max.Cross Travel		mm	165
Distance Between Table Surface and Spindle Center		mm	360
Max.Table Load		kgs	100
T-Solt(Number×Width)		mm	1×14
Table Speed		m/min	manual
Crossfeed Handwheel	1gard	mm	0.01
	1 rev		2.5
Automatic Crossfeed of Saddle		mm	-
Power Cross Feed	50HZ	mm	-
	60HZ		-
Grinding Wheel Dimensions		mm	1801332/31.75
Spindle Speed	50HZ	rpm	2850
	60HZ		3420
Vertical Handwheel	1gard	mm	0.005
	1 rev		1.25
Automatic Down Feed Rate		mm	—
Power Head Increment		mm	—
Spindle Motor		kw	1.1
Vertical Motor		w	—
Hydraulic Motor		kw	-
Dust Collection Motor		w	550
Coolant Motor		w	90
Crossfeed Motor		w	-
Floor Space		mm	1900×1300
Packing Dimensions		mm	110010201945
Net Weight		kgs	620
Gross Weight		kgs	710

Detailed pictures for your reference

If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
