Help Center250KG Forging Hammer for Sale C41-250
Related Products
-
Air Hammer C41-25KGNegotiableMOQ: 1 Set -
Air Hammer Pneumatic Power Forging Hammer C41-75kgUS$ 1,500 - 2,000MOQ: 1 Set
-
High Quality Forging Hammer C41-16KG,forging Hammer Power Hammer,air Hammer C41 for SaleUS$ 1,500 - 2,000MOQ: 1 Set
-
6kg Air Power Hammer Metal Forging Hammer C41-6(integrated)US$ 1,000 - 10,000MOQ: 1 Set
-
China Manufacturer Mini Air Hammer C41-20KG With Low PriceUS$ 500 - 50,000MOQ: 1 Set
Forging Hammer is widely used with flat die or special die for various forging works,such as drawing-out, upsetting, punching, chiseling, forging, welding, bending and twisting. It is also used for open die forging bolster dies.
Because this Pneumatic Forging Hammer doesn’t use steam and compressing air,so it doesn’t need to install steam boiler,air compressor and air or steam pipe.Therefore you only need to invest less fund and time for establishing new factory.It is economically used by repair shop and large or small factory.
Pneumatic Forging Hammer can’t be used for closed forging.Because the strong power would break off the hammer rod while used in closed die forging.
Pneumatic Forging Hammer is operated with operating handle ,that could process six action cycle.----Idle run,lift hammer,press hammer light hit,wham and single hit,the workpiece must be put on the bottom anvil surface and opposite to the upper hammer die,only this could hit stably the workpiece to the shape you want.
Technical Specifications | ||||
1 |
Weight of falling parts |
Kg |
250 |
|
2 |
Max. hit energy |
Kj |
5.6 |
|
3 |
Hit number |
min -1 |
150 |
|
4 |
Distance from bottom die surface to bottom surface of lead |
mm |
450 |
|
5 |
Tup axis to hammer body |
mm |
430 |
|
6 |
Dimension of top die surface |
mm |
220 X 100 |
|
7 |
Dimension of bottom die surface |
mm |
220 X 100 |
|
8 |
Distance from botton die surface to base |
mm |
750 |
|
|
Motor |
Type |
-- |
180L-4 |
|
Rate power |
kw |
22 |
|
9 |
Speed |
r.p.m |
1470 |
|
10 |
Overall dimension |
mm |
2875 X 1405 X 2570 |
|
11 |
Anvil Weight |
kg |
~3000 |
|
12 |
Total Weight |
kg |
~8000 |
|
