Product Details
Condition: | New | Place of Origin: | Hunan, China | Brand Name: | TOP |
Model Number: | TOP3000 | Voltage: | 380 | Rated Power: | 9 |
Dimension(L*W*H): | 1020*770*1270 | Weight: | 293KG | Certification: | ISO,CE |
Warranty: | 10 years | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CNC table cutting machine details data:
Model | TOP3000 | TOP5000 | TOP7000 | TOP10000 |
Voltage(V) | 380 ±10%,50/60Hz,three phase | |||
Rated capacity(KVA) | 9 | 15 | 22 | 31 |
Working pressure(Mpa) | ≤0.2 | |||
Relative humidity(%) | ≤90 | |||
Rated gas output(L/H) | 3000±10% | 5000±10% | 7000±10% | 10000±10% |
Water consumption(L/H) | 1.6 | 2.7 | 3.8 | 5.8 |
Maximum Cutting Thickness(mm) | 110 | 220 | 310 | 420 |
Effective perforated thickness(mm) | 40 | 60 | 70 | 90 |
Cooling way | Air cooling | |||
Insulation class | F | |||
power protection grade | IP2S | |||
Flame temperature(℃) | 800-3200 adjustable | |||
Working medium | Filtered water or deionized water or soft water | |||
Working | continuous | |||
environment temperature(℃) | 0-40 | |||
Dimension(L×W×H)mm | 1020*770*1270 | 1250*830*1720 | 1300*930*1820 | 1500*930*1940 |
Weight(KG) | 293 | 567 | 653 | 894 |
Click here can know more product details
What is the application of our oxyhydrogen cutting machine ?
Oxy-hydrogen cutting machine in the glass industry, quartz glass processing applications
1.Carbon Steel Cutting of machine building industry,shipyard,steel structure processing plant.
2.Continuous casting slab cutting of Steel Plant.
3.Cooperate with manual cutting torch, semiautomatic cutting machine, shape cutting machine, CNC cutting machine to instead of traditional fuel gas
What is the Advantages of our oxyhydrogen cutting machine?
Save time & money
No acetylene, no propane, no oil, just water for metal cutting .The temperature of the oxyhydrogen flame is up to 2800 degrees Celsius, and the flame is more concentrated. Compared with conventional fuel, more save time and cost.
Small incision
The oxy hydrogen flame is concentrated , and fire point is precise.
Safety and Pro-environment
Because the density of hydrogen is small, will not assembled on the ground,so there is no risk of explosion; designed 3 Alert trigger system, whole process is clean, no pollution.
Convenient and High-tech
With the latest technologies, It is able to cut 50-500mm,and easy to use.
Low carbon environmental protection
The all cutting process is just consume water, 1 litre water can produce 1860 litre oxy-hydrogen nsume about 4KW/H,oxy-hydrogen gas is no color,no taste,no harm ,no CO,no CO2,is very pure.
Company Information
Our company is located in Changsha city, Hunan province, China. We are a professional manufacturer of researching and producing oxy-hydrogen generators, carbon clean machines, cutting machines, welding machines and other machines. We have strong production and export experience. Our machines are widely used in the world.
In the technology, we are devoted to improving old products and developing new products, and doing our best to meet market demands.
In the manpower, we have a professional technology development team with 10 technical personnel and more than 50 production staff members as well as a 20-person sales team.
Hntcny is also providing green energy solutions. We are specializing in Oxy-Hydrogen Generators, which change ordinary soft water into a clean burning fuel that can be used to replace traditional gas fuels. We offer this safe, clean and pollution-free new source of green energy for mankind. Our development philosophy is based on creating a cleaner living environment around the world and promoting the use of sustainable energy sources.
Hntcny Engine Carbon Cleaning Machine consumes water and electricity to create oxy-hydrogen gas which feeds into to the engine for cleaning the accumulated carbon and increasing the combustion efficiency of the existing fuel. There is no pollution, no harmful gases or chemical additives to harm you, you engines or the environment.
