Chain Bending and Welding Machine
US$ 1 - 2
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
BOBO
Model Number:
UNB-350
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
BOBO
Model Number
UNB-350
Condition
New
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Chain bending and welding machine1- Chain conveying
2- Chain rotating
3- Chain welding
4- Chain forging
Automatic chain welding machine, chain link welding machine, chain making machine, anchor chain equipment, chain production line.
Chain bending and welding machine, chain link formign machine, chain forming machine, chain bending machine
The machine used to welding the chain with secondary resistance electrify method, include the chain conveying, rotating, wedling, forging, trimming, ect 19 actions in automatic work.
Working process:
1- Chain conveying
2- Chain rotating
3- Chain welding
4- Chain forging
5- Chain trimming
Technical data
| Model: UNB-125C |
| Suitable wire diameter: 4-8mm |
| Chain pitch: 2.7 ~ 5.0 times of wire diameter |
| Productivity: 40-50 rings/min |
| Rated capacity: 125KVA, 50Hz |
| Open circuit voltage: 3.52~7.04 V (8 grade) |
| Motor capacity: 2.2KW, 1500rpm speed |
| Pneumatic pressure: 0.6MPa |
| Air consumption: 7L / cycle |
| Cooling water consumption: 18L/min, min. degree 15 centigrade. |
| Machine dimension: 2200 x 1350 x 1900mm |
| Machine net weight: 2160KG |
