Home > Manufacturing & Processing Machinery > Plastic Machinery > Foam Machinery > Polyurethane Insulation Spray Machine
US$ 10,000 - 12,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, foam machine
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
polyurethane insulation spray machine will be delivered from Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Polyurethane Foam Spray Insulation MachineUS$ 10,000 - 12,000MOQ: 1 Set -
Spray Foam Roof Insulation MachineUS$ 10,000 - 12,000MOQ: 1 Set
-
High Pressure PU Foam Injection MachineUS$ 6,000 - 25,000MOQ: 1 Set
-
Pipe Insulation MachineUS$ 10,000 - 12,000MOQ: 1 Set
-
HP Foam Injection Machine for Insulation PipeUS$ 6,000 - 25,000MOQ: 1 Set
Condition
New
Product Type
Other, foam machine
Place of Origin
Jiangsu, China
Brand Name
BOBO
Model Number
BDF-III
Voltage
220V, 50Hz, single phase (can be customized)
Power(W)
7Kw
Dimension(L*W*H)
800x700x1100mm
Weight
200Kg
Certification
Other, ISO9001
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
polyurethane insulation spray machine1.Pneumatic motor
2.High precision proportion pump
3.Main machine heating system
polyurethane insulation spray machine
The polyurethane insulation spray machine is design for sitework, with accuracy measuring, even mixing, moveable and portable structure and balance of cost and performance. The HP foam spraying machine is widely used for wall, roof, refrigerator, and box, pipe insulation purpose.
Feature of polyurethane insulation spray machine
1 Pneumatic motor
2 High precision proportion system
3 Main machine heating system
4 Hose heating system
Main technical data of polyurethane insulation spray machine
| Model | BDF-III |
| Max. Flux capacity | 2-6.8kg/min |
| Max. material temperature | 90 centigrade |
| Mixing pressure | 5-10Mpa(700-1500PSI) |
| Heating capacity | 7Kw |
| Max. hose length | 60m |
| Driving method | Pneumatic with air compressor |
| Motor power | 220V, 50Hz, single phase (can be customized) |
| Dimension | 800x700x1100mm |
| Weight | 200Kg |
| Main machine with variable mixing ratio | 1:1 to 2:1 |
