Specifications
The Polyurea spray equipment waterproof is used to spray polyurea on wall, tank, etc for waterproof, abrasion purpose, etc
Polyurea spray equipment waterproof
The Polyurea spray equipment waterproof is used to spray polyurea on wall, tank, etc for air proof, abraion purpose.
We can supply both high pressure spray foam machine and low pressure spray foam machine for option.
Feature of Polyurea spray equipment waterproof
1- Pneumatic motor
The pneumatic motor adopt the lastest direction-change for double direction work, has more stable
performance compare to electric one, suitable for complicated sitework condition.
2- High precision proportion pump
The proportion pump is made from stainless steel, to reduce the abrasion to seals, lengthen the
machine life. Equipped with oil tank for DOP solvent to clean the scrap material.
3- Main machine heating system
The main machine adopt separate aluminum heater, equipped with powerful heating bar for better
heating capacity, suitable for low temperatuer work in winter. The temperature control system with
number display, with measuring and overload protection system to control temperature exactly.
Main technical data of Polyurea spray equipment waterproof
Model | BDF-V |
Max. Flow capacity | 2-8kg/min |
Mixing ratio | 1:1, fixed ratio |
Material viscosity range | 200-1000CPS (Operation temperature) |
Max. System pressure | 25MPa |
Single material output press | Max.26MPa |
Hydraulic pressure | 8-12MPa (for working) |
Material heating capacity | 9000W X 2 |
Hose heating capacity | 3200W |
Max. Hose length | 90M |
Electric system | 38A x 3 + 16A -380V 3Phase |
Driven system | Full-hydraulic |
Cleaning system | Pneumatic cleaning |
Dimension | 1100x700x1400mm |
Weight | 350KG |
Standard configuration | Main machine, one set Feeding pump, two pieces Spray gun, one piece Gun connection hose 1.5 m, one set Heating hose 15m, one set |
