Polyurethane foam injection machine
USD $9,000 - $20,000
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Product Type | Other, polyurethan foam product | |
| Place of Origin | Jiangsu, China | Brand Name | BOBO | |
| Model Number | GZ-30/50 | Voltage | 380V | |
| Power(W) | 5.5KW | Dimension(L*W*H) | 2000X2200X1800mm | |
| Weight | 1800kg | Certification | CE, Other, CE, ISO | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Polyurethane foam injection machine1- Low pressure M/C for fleixble foam
2- High pressure M/C for rigid foam
3- with ISO CE
Polyurethane foam injection machine
The polyurethane foam injecting machine is mainly used for continuous injecting rigid or soft polyurethane foam for various thermal insulation purposes.
air/ oil/ flue fitler foam injection machine. ployurethane foam injection machine, foam injecting machine, foam generator, foam spraying machine, foam sprayer
Espuma de máquina injetora. ployurethane máquina da injeção da espuma, máquina da espuma injetável, gerador de espuma, máquina de pulverização de espuma, pulverizador da espuma
Main technical data
- Main pump motor power: 2.5kW
- Mixing motor power: 0.75kW
- Hydraulic pump motor power: -
- Auto glue filling motor power: 2.2kW (two set for two tanks)
- Flux: 0~6kg per minute
- Capacity of the tanks for polyurethane glue: 180kg each, auto filling glues
- PLC automatic control: PLC programmable, automatically heating, injecting, cleaning and blowing; Special PLC system from Chinese domestic which can save 99 programs.
- Equipped piston type measuring pump: HJ30-50 (two), adjusting accuracy 0.05%.
- Generating pressure: 8-10MPa (one 0.8 m3 air compressor is equipped by buyer)
- Machine weight: about 600kg
- Dimension: 1370mm x 1350mm x 2250mm
