Specifications
1- Feeding2- Clamping
3- Welding
4- Annealing
Spot welding machine, potint welding machine, spot welder
Seam welding machine, seam welder, stitch welding machine,stitch welder
Model | Rated power (KVA) | Primary voltage (V) | Load duration factor (%) | Arm length (mm) | Distance between arms (mm) | Stroke of top electrode (mm) | Pressure of compressed air (MPa) | Cool Water flux (L/min) | Max. welding thickness (carbon steel mm) | Dimension (L x W x H) (mm) |
DN-35 | 35 | 380 | 50 | 380 | 210 | 20-80 | 2-5 | 5 | 3+3 | 900 x 560 x 1540 |
DN-50 | 50 | 380 | 50 | 430 | 280 | 20-80 | 2-5 | 9 | 3.5+3.5 | 1170 x 680 x 1670 |
DN-63 | 63 | 380 | 50 | 440 | 280 | 20-80 | 2-5 | 9 | 4+4 | 1170 x 690 x 1680 |
DN-75 | 75 | 380 | 50 | 450 | 270 | 20-80 | 2-6 | 13 | 4.5+4.5 | 1180 x 680 x 1700 |
DN-100 | 100 | 380 | 50 | 470 | 270 | 20-100 | 2-6 | 13 | 5+5 | 1200 x 710 x 1700 |
DN-125 | 125 | 380 | 50 | 460 | 270 | 20-100 | 2-6 | 13 | 5+5 | 1200X710X 1700 |
DN-150 | 150 | 380 | 50 | 460 | 270 | 20-100 | 2-6 | 13 | 5.5+5.5 | 1200 x 710 x 1700 |
DN-200 | 200 | 380 | 50 | 460 | 260 | 20-100 | 2-6 | 15 | 6+6 | 1250 x 770 x 1800 |
