Equipment for HVAC spiral
- 6 Set / Sets per Month
- Shanghai
- T/T
- CNC router for stone processing engraving machine
- Glass polishing machine JMB95A
- Aluminum Profile Bending Machine/Arc Bending Machine for Aluminum
- Automatic aluminum window corner connector cutting machine
- aluminum door and window frame cutting machine aluminum windows and doors machine
- Upvc Window Door Machine Four Head Welding Machine for PVC welding Window Machine
Product Details
Condition: | New | Type: | Pipe Molding Machine | Pipe Material: | Stainless Steel |
Application: | Other, Ventilation duct | Place of Origin: | Jiangsu, China | Brand Name: | BOBO |
Model Number: | BTF-II | Voltage: | 380V | Power(W): | 11.5KW |
Dimension(L*W*H): | 2000X2000X1500 | Weight: | 2.45T | Certification: | CE |
Warranty: | One year |
Product Description
Specifications
Equipment for HVAC spiral1- spiral duct machine
2- spiral tubeformer
3- spiral pipe forming machine
4- spiral duct former
Equipment for HVAC spiral
1- spiral duct machine
2- spiral tubeformer
3- spiral pipe forming machine
4- spiral duct former
The spiral duct forming machine BTF-II is used to produce the round rigid air duct for ventilation purpose, diameter from 100-1600mm, with wall thickness up to 1.2mm galvanized steel.
Main technical data
- 1. Diameter of round tubes: 100mm ~ 1600mm.
- 2. Max. tube length: unlimited.
- 3. Thickness of strip: 0.4 ~ 1.20mm
- 4. Width of strip: 137mm
- 5. Strip speed: 1~38m/min, adjustable
- 6. Suitable strip material: aluminum, stainless steel, galvanized steel, color coated steel, etc.
- 7. Dimension: 3500mm x 2800mm x 2580mm (can be loaded in one 20’ container, disassembled, 8. in case 3000x2000x2200)
- 9. Weight: 2500kg
- 10. Power of main motor: 5.5kw
- 11. Power of cutting motor: 4kw
- 12. Pressure of pneumatic hydraulic station: 8kgf/cm2
Key words: spiral tubeformer, spiral duct forming machine, ventilationd duct machine, spiral tube former, spiral duct former, ventilationd duct machine, HVAC duct machine.
