Home > Manufacturing & Processing Machinery > Building Material Making Machinery > Pipe Making Machine > Spiro Duct Machine
US$ 20,000 - 55,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Pipe Molding Machine
Pipe Material:
Stainless Steel
Payment & Shipping
Payment Methods:
Port of Shipment:
spiro duct tubeformer machine will shiped from Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Type
Pipe Molding Machine
Pipe Material
Stainless Steel
Application
Other, Ventilation duct
Production Capacity
35m/min
Place of Origin
Jiangsu, China
Brand Name
BOBO
Model Number
BTF-II
Voltage
380V or customized
Power(W)
15KW
Dimension(L*W*H)
3500X2000X2600mm
Weight
2500kg
Certification
ISO, CE
Warranty
One year
After-sales Service Provided
Engineers available to service machinery overseas
Spiro duct machine
The spiro duct tubeformer machine BTF-II is used to produce the round rigid air duct for ventilation purpose.
Feature
- lock seam can be inner or outer lock for option.
- PLC control system with button operation
- Fast change steel duct mould
- Cutting systm can be plasma and roller shear for option.
| 1 | Diameter | 100-1600mm |
| 2 | Thickness | 0.4-1.2mm |
| 3 | Strip width | 137mm |
| 4 | Strip feeding speed | 1-30m/min, adjustable |
| 5 | Suitable material | Galvanized steel, stainles steel |
| 6 | Main motor power | 15KW |
| 7 | Hydualic motor power | 4KW |
| 8 | Air compressor | 0.8MPa |
| 9 | Dimension | 3500 x 2800 x 2580mm |
| 10 | Weight | about 2500KG |
spiral tubeformer, spiral duct forming machine, ventilationd duct machine, spiral tube former, spiral duct former, ventilationd duct machine, HVAC duct machine, air duct machine.
