Single lock flexible metal hose machine

Specifications

Single lock flexible metal hose machine
1- Square lock
2- More flexibility
3- Quick change mould
4- Easy maintenance

Single lock flexible metal hose machine

The Single lock flexible metal hose machine is used to produce flexible hose from metal strip by spiral lock forming, and the finished flexible hose is mainly used for cable casing, electric hose and shower hose, etc. The metal strip can be stainless steel, galvanized steel and aluminum, etc.





Feature of Single lock flexible metal hose machine

• The flexibility is adjustable by change lock seaming
• Automatic lubrication and cooling water recycling system
• Adjustable lock forming roller for different thickness
• Speed control by inveter to match forming and collecting speed





Main technical data of Single lock flexible metal hose machine





1	Diameter Range	3/8" to 4"
2	Strip width	9.5-25.5mm
3	Strip thickness	0.2-0.5mm
4	Forming speed	about 2m/min
5	Motor power	2.2-3.0 KW x 2
6	Dimension	900 x 900 x 1200mm (base on machine size)
7	Weight	800-1200KG
