Hydraulic Carton Baler Press

Hydraulic Carton Baler Press photo-1
Hydraulic Carton Baler Press photo-2
Hydraulic Carton Baler Press photo-3
US$ 2,000 - 4,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Cardboard baler
Packaging Type:
Other, Compressed bale
Payment & Shipping
Payment Methods:
Port of Shipment:
Hydraulic carton baler press will be shipped to SHANGHAI port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Cardboard baler
Packaging Type Other, Compressed bale
Packaging Material Other, Rope, Wire, etc
Automatic Grade Semi-Automatic
Driven Type Hydraulic
Voltage 380V or customized
Power 2.2kw, 2.2kw
Place of Origin Jiangsu, China
Brand Name BOBO
Model Number PB10-6040
Weight 800kg
Dimension(L*W*H) 900*650*2100mm
Certification ISO CE
After-sales Service Provided Engineers available to service machinery overseas



Hydraulic carton baler press



Product Description

 Hydraulic carton baler press

Hydraulic Carton Baler Press

This hydraulic carton baler press is the standard baling machine, are most popular for its widely using range. It is used for baling cartons, cotton yarn, plastic, wood, etc. It is designed as vertical structure, hydraulic Transmission, electrical control and manual binding. Also, we can produce the machine according to the requirement from customer



Hydraulic carton baler press

Feature of  Hydraulic Carton Baler Press





  • Hydraulic driven for smooth wok
  • The pressing plate use the guide groove type balance, effectively prevent slope
  • Linking type auto turn over bale, safe and easy
  • Auto control mode, safety interlocking device
  • Monitor shows working condition, to ensure monitoring machine operation effectively
  • Preset pressure, prevent overload protection
  • Intelligent control, self-check program
  • Install emergency stop button independently, can stop machine anytime
  • Quick locking and releasing device, safe and efficient
  • High strength framework design, can afford double pressure to ensure the durability of the machine

Hydraulic carton baler press

Main technical data of hydraulic carton baler press:

Model

PB10-6040

Force

10 Ton

Bale size(mm)

600*400*300-600

Bale weight

30-50kg

Efficiency

4-6bales/hr

Power

2.2kw

Machine weight

800kg

Dimension(mm)

900*650*2100

Other models maybe you are interested:

Model

Force

Bale size(mm)

Bale weight

Efficiency

Power(kw)

Machine weight

Dimension(mm)

PA10-6040

PB10-6040

10 Ton



600*400*300-600



30-50kg



4-6bales/hr



2.2



800kg



900*650*2100

PA20-8060

PB20-8060

20 Ton



800*600*400-900



80-100kg



4-6 bales/hr



4



950kg



1000*750*2750

PA30-8060

PB30-8060

30 Ton



800*600*400-900



100-130kg



4-6 bales/hr



5.5



1000kg



1000*750*2750

PA30-M1070

PB30-M1070

30 Ton



1100*700*450-1000



130-150kg



4-6 bales/hr



5.5



1200kg



1350*850*3200

PA40-M1070

PB40-M1070



40 Ton



1100*700*450-1000



150-200kg



4-6 bales/hr



7.5



1800kg



1350*850*3200

PA40-M2080

PB40-M2080



40 Ton



1200*800*500-1100



200-240kg



4-6 bales/hr



7.5



2050kg



1600*1050*3300

PA50-M2080

PB50-M2080



50 Ton



1200*800*500-1100



250-320kg



4-6 bales/hr



7.5 or 11



2600kg



1600*1050*3300

PA60-M5075

PB60-M5075



60 Ton



1500*750*500-1100



380-420kg



4-6 bales/hr



11 or 15



2900kg



1850*1150*3300

PA80-M5075

PB80-M5075



80 Ton



1500*750*500-1200



450-480kg



4-6 bales/hr



15



3300kg



1850*1150*3300

PA100-M5075

PB100-M5075



100 Ton



1500*750*500-1200



500-550kg



4-6 bales/hr



15kw



3700kg



1850*1150*3300

 Hydraulic carton baler press

Hydraulic carton baler press

Hydraulic carton baler press











FAQ

 Hydraulic carton baler press



1. Q: What is the power supply of the machine?

    A:  The standard power supply in china is 380V, 3P, 50Hz. We also can customized accordingly.

2. Q: What information should the customer provide to get an accurate quotation from us?

    A: The customer should provide the pressing material, bale size and weight, industrial voltage, planned output to us.

3. Q: When we received the machine, how to install it?

    A: The machine has been installed already before shipment, when you recieved, just need to connect the electric and fill in the hydraulic  oil.

4. Q: How to maintenance baling machine?

    A: Don't exposed to the sun and rain, replace the hydraulic oil at fixed period.

5. Q: What is the delivery time?

    A: Normally the delivery time of the machine is 20 days after receive down payment.

6. Q: What is the warrantee period of the machine?

     A: The warrantee period is one year since the date of B/L.



Packaging & Shipping

 Hydraulic carton baler press

Packaging:

Stable wooden package protects machine from strike and damage.

Wound plastic film keeps machine out of damp and corrosion.

Fumigation-free package helps the smooth customs clearance.

The big size machine will be fixed in container without package.



Shipping:

For LCL, we cooperated with reputable logistics team to send machine to sea port speedily and safely.

For FCL, we get the container and do container loading by our skillful workers carefully.

For forwarders, we have professional and long term cooperated forwarders who can handle the shipment smoothly.

Also we would like to have seamless cooperation with your forwarder at your convenience.

Hydraulic carton baler press

Hydraulic carton baler press



Our Services

 Hydraulic carton baler press



1.Professional and patient consulting service to help you find the suitable solution.

2.Further negotiation about the technical details, machine configuration, price basis, payment term and delivery time.

3. Powerful control of the machine production schedule and quality, and keep you posted about details in time.

4.Free training and accommodation in our plant during machine inspection. Or  photos and video of the machine and package

for your confirmation before shipment.

5.Quick and safe shipment as per your requirement including the booking ,container loading, and shipping documents.

6.For technical support, we can help you online by email and phone, also we can send technicians to your site if necessary.

7.For the spare parts, we will supply the parts for free during one year guarantee period, also the parts supplying at original cost after that.



Company Information

 Hydraulic carton baler press

BOBO MACHINE CO., LTD is the professional supplier for metal processing machinery in China. We supply the

duct machine, pu foam machine, baling machine, leather machine, wheel production line and different kinds of metal

processing machinery.



With many years successful industry experience, we have established long term cooperation with lots of customer from

all over the world. Also we have sales network in Britain, Russia, USA, Mexico and Brazil to supply the machine and

service in local market directly.Also we can work as your professional consulting advisor in China to sourcing the right

machine and equipment as per your requirements, to offer you the complete solution and necessary after sale service.



 “Professional and creditable, customer first”, with these work faith, we successfully win the expanded market and

 favorable feedback from our customers, and we always look forward to be your reliable supplier and advisor in China, to

 have a long term cooperation for mutual benefit.
