IW Diamond Insert Extrusion Wire Guides

IW diamond insert extrusion wire guides

The unique combination of hardness and toughness renders tungsten carbide guide one of the most wear-resistant
Tungsten carbide guide can be diamond polished to a mirror finish as smooth as 0.025-0.05 micron or 1-2 micro inches Ra, for processing ultra-fine wires
It is particularly adaptable to dynamic applications, such as: on flyer bows in bunching and stranding, where guide breakage is an issue, in spite of its heavier unit weight
While most ceramics except black Titania are insulators, tungsten carbide is electrically conductive
This feature makes it the guide of choice for static dissipation in fiber processing
Dimensional drawings of the more popular carbide guides (excluding coil winding nozzles) which we offer are introduced in this page
Additional carbide guides can be found under the respective product categories designated by the capital letter "T" in the first digit in the part number
We offer to create molds for tungsten carbide wire guides in the form of bow guide, eyelet guide and ring guide and drawing dies

About our company

• Zhuzhou Hongtong Tungsten Carbide Co. Ltd is one of the most professional cemented carbide manufacturers located in Zhuzhou City, the world-renowned cemented carbide hometown
• Having been involved in this field for over 14 years, we have rich experience in both production and research of carbide products
• Europe, Asia, Africa, and Middle East are our current markets

Quick details:

• Place of origin: Zhuzhou, China
• Chemical composition: WC + cobalt
• Surface color: blanks ungrounded of grinding polished

MOQ:

• Could be 100 pieces or 1kg
• But the price will be a little bit high when the quantity below 50kg or $2000

Sample:

• Samples are available upon customers request
• Sample time is 7 days
• Sample sent by DHL, UPS, FedEx, EMS, China Post Airmail

Delivery time:

• For standard types, the delivery time is normally 20-25 days
• For nonstandard type or further processed type, the delivery time is 25-35 days
• For urgent needs, delivery time may be pushed by negotiation

Payment method:

• T/T, 30% deposit, balance payment before shipment
• Other payment methods such as PayPal

Grade No. and Application:
