Stainless steel full cone spray nozzle
Product Information:
1. Wide Spray ,spray angle :43-107degree.
2. Spray pattern: Full cone
3. Material: Stainless Steel 303; Stainless Steel 304; Stainless Stell 316; and Brass
4. Thread size: 1/8" to 1/2" BSPT or NPT (Male thread)
5. Working Pressure: from 0.5bar to Dozens of bar; Usually, nozzles will spray perfectly under 3bar or larger pressure.
6. Frow rate @ 3bar pressure: From 0.38L/min to 183L/min
7. Stainless steel standard angle full cone spray nozzle has removable cap and vane
8.Connection : Adjustable fitting; Split-Eyelet
Design Features:
1.Solid cone-shaped spray pattern with round impact area.
2.Uniform distribution over a wide range of flow rates and pressures.
3. Medium- to large-sized drops.
4. Unique vane design with large flow passages provides superior control and uniform distribution.
Specification:
| Type | Inlet size | A(mm) | B(mm) | N.W. |
|
1/8" | 32.5 | 14.3(Hex.) | 0.02 |
| 1/4" | 39.5 | 17.5(Hex.) | 0.04 | |
| 3/8" | 47 | 20.6(Hex.) | 0.07 | |
| 1/2" | 56.5 | 25.4(Hex.) | 0.17 |
Applications:
Washing/rinsing
Gas scrubbing, washing, cooling
Foam break-up, aeration, deaeration
Fire suppression/prevention
Dust control
Creation/dispersion of drops in chemical reaction processing
Cooling coke,primary metals and other materials
Performance Parameter Table:
Spray Pattern:
