2500kg Hand Pallet Trucks

Name: 2500kg Hand Pallet Trucks
Brand: Eagle
SKU: 140924972
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

Eagle

Model Number:

HPT25A

Eagle Industries, Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name Eagle

Model Number HPT25A

Type Manual Pallet Truck

Rated Loading Capacity 2500KG

Max. Lifting Height 115mm

Min. Lifting Height 85mm

Fork Length 1220mm

Fork Width 685mm

Specifications

2500kg hand pallet trucks
1.All of the products certificate: CE and GS
2.Capacity from 2500Kg
3.Fork Width:685mm

2500kg hand pallet trucks

Model:HPT25A

Features

Full hydraulic system. Bullet connection between steering shaft and pump piston.
It is convenient to replace the rear wheel.
Easy to maneuver with 210 degrees turning radius.
Special lowering valve to control the trucks durable.
Number of pump strokes-10.Lift height per stroke:12mm.
Reliable oil leak-proof hydraulic system.
12 lubrication grease nipples on all movable parts for easy maintenance.
Adjustable pump cap ensure a long service life.
Reinforced for added strength of load capacity.
Ergonomic Large Rubber handle with three control lever.

Model	Unit	HPT25A-SN	HPT25A-BN	HPT25A-SP	HPT25A-BP
Capacity	Q(kg)	2500
Service weight	kg	65-80
Steering wheel	mm	φ200
Fork wheel	mm	φ80
Number of fork wheel		Single	Both	Single	Both
Material of wheels		Nylon		Polyurethane
Max. lift height	h3(mm)	115
Total height	h14(mm)	1224
Lowered fork height	h13(mm)	85
Overall length	l1(mm)	1603
Fork dimensions	s/e/l	45/160/1220
Distance between fork-arms	b5(mm)	685
Ground clearance centre of wheelbase	m2(mm)	40
Aisle width for pallets 1000x1200 crossways	Ast(mm)	1733/1803
Aisle width for pallets 800x1200 lengthways	Ast(mm)	1783/1803
Turning radius	Wa(mm)	1266/1336
Item No.		233021	233022	233023	233024
