Hand Pallet Truck

Specifications

Model:HPT30A
1.All of the products certificate: CE and GS
2.Capacity from 3000Kg
3.Fork Width:550mm
4.Fork Length:1100mm

Hand Pallet Truck

 Model:HPT30

Features

Full hydraulic system. Bullet connection between steering shaft and pump piston. It is convenient to replace the rear wheel. Easy to maneuver with 210 degrees turning radius. Special lowering valve to control the trucks durable. Number of pump strokes-10.Lift height per stroke:12mm. Reliable oil leak-proof hydraulic system. 12 lubrication grease nipples on all movable parts for easy maintenance. Adjustable pump cap ensure a long service life. Reinforced for added strength of load capacity. Ergonomic Large Rubber handle with three control lever.

Model		HPT30-SN	HPT30-BN	HPT30-SP	HPT30-BP
Capacity	Q(kg)	3000
Service weight	kg	65-80
Steering wheel	mm	φ200
Fork wheel	mm	φ80
Number of fork wheel		Single	Both	Single	Both
Material  of wheels		nylon		polyurethane
Max. lift height	h3(mm)	115
Total height	h14(mm)	1224
Lowered fork height	h13(mm)	85
Overall length	l1(mm)	1483
Fork dimensions	s/e/l	45/160/1100
Distance between fork-arms	b5(mm)	550
Ground clearance centre of wheelbase	m2(mm)	40
Aisle width for pallets 1000x1200 crossways	Ast(mm)	1733/1803
Aisle width for pallets 800x1200 lengthways	Ast(mm)	1783/1803
Turning radius	Wa(mm)	1266/1336
Item No.		233027	233028	233034	233035
