Home > Manufacturing & Processing Machinery > Machine Tools > Milling Machine > Universal Vertical And Horizontal Milling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Eagle
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Shandong, China
Brand Name
Eagle
Model Number
VHM 30
CNC or Not
Normal
Certification
CE
Type
Other, Vertical
Specifications
Universal Vertical And Horizontal milling Machine| Universal Vertical And Horiontal milling Machine | |||||||
| Model | Unit | VHM 30 | VHM 30A | VHM 30B | |||
| table size | mm | 300×1300 | 300×1300 | 300×1500 | 300×1370 | 300×1500 | |
| Table longitudinal travel manual | mm | 845 | 845 | 1000 | 880 | 1000 | |
| Table cross travelmanual | mm | 385 | 385 | 385 | 380 | 380 | |
| Knee vertical travelmanual | mm | 435 | |||||
| Table longitudinal feed rate | mm/min | 0-3500Servo Motor | |||||
| Table cross feed rate | mm/min | 0-3500Servo Motor | |||||
| Knee rapid speed | mm/min | 900 | |||||
| Vertical Spindle | Motor power | HP | 5HP | Standard: 3HP/optional: 5HP | |||
| Speed | rpm | (Standard: 16 steps ) : 50HZ: 65-4500 60HZ: 80-5440 (optional: variable speed): 653750 | |||||
| Taper | ISO40 | Standard: R8 / optional: ISO40 | |||||
| Quill travel | mm | 127 | |||||
| Quill feed | mm/rev | 0.04 /0.08 /0.15 | |||||
| Head rotating | R/L) 90° | R/L) 90°B/F45° | |||||
| Distance from spindle end to table surface | mm | 115~545 | |||||
| Horizontal Spindle | Motor power | HP | 5HP | ||||
| Speed | rpm | 50HZ: 45/80/165/260/500/980 60HZ: 55/100/200/315/600/1180 | |||||
| Taper | ISO40 | ||||||
| Distance from spindle center to table surface | mm | -20410 | |||||
| Distance from spindle center to ram | mm | 183 | |||||
| Ram travel | mm | 480 | |||||
| Ram rotating | 360° | ||||||
| Net weigh | Kg | 1900 | 1900 | 1950 | 1680 | 1730 | |
| Package size L×W×H | cm | 180×150×220 | 180×150×220 | 180×180×220 | 180×160×220 | 180×180×220 | |
| Item NO. | 132010 | 132020 | 13021 | 132030 | 132031 | ||
| Standard equipment: | Optional equipment: | ||||||
| Electro cabinet and hung up control panel | X/Y axis inverter motor power feed 0-3500mm/min | ||||||
| Knee rapid elevating motor | X/Y axis gear box power feed | ||||||
| Cooling system | X/Y axis power feed | ||||||
| Electro lubricate pump | Digital readout | ||||||
| Draw bar | Air draw bar (for vertical spindle) | ||||||
| Oil collecting plate | Horizontal milling tools arbor | ||||||
| Working lamp | Inverter vertical milling head | ||||||
| Plastic splashing guard | Variable speed vertical milling head | ||||||
| Leveling wedge and screw | |||||||
