RADIAL DRILLING MACHINE

Name: RADIAL DRILLING MACHINE
Brand: Eagle
SKU: 140924762
Availability: InStock

Eagle Industries, Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

Eagle

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name Eagle

Model Number DR 700/DR 700C

CNC or Not Normal

Certification CE

Specifications

RADIAL DRILLING MACHINE
With wide range of speed and feed,with manual,power and fine feeds.

RADIAL DRILLING MACHINE

1.With wide range of speed and feed,with manual,power and fine feeds.The feed of machines are very easily engaged and disengaged at any time.

2.Integrating technology for casting parts is excellent,adopting casting equipment, ensuring high quality of materia for basic parts.

3.The radial arm can rotated and can tilted±45° ,it reliable and easy jo can be done.

4.The machine with small appearance and much function,the machine are widely used for drilling, counterborin,reaming,tapping etc.

Model	Unit	DR 700	DR 700C
Max.Drilling capacity	mm	31.5
Max.tapping capacity	mm	Cast iron 20/Steel 16
Distance spindle axis to column generating line	mm	300~700
Diameter of column	mm	150
Spindle taper		MT3
Spindle travel	mm	130
Spindle speeds range	r/min	100~1600
Spindle speeds series		8
Range of Spindle feeds	mm	0.080.140.23
Max.Distance spindle nose to working surface of base	mm	275680
Dimension of worktable	mm	250×250×250
Dimension of base	mm	1050×550×120	1200×625×155
Overall Size	mm	1235×550×1195	1235×625×1230
Power of Main motor	kw	750/1100
G.W/N.W	kg	475/380	675/580
Packing dimension	mm	1220×620×1280	1270×690×1370
Item NO.		146020	146021
